Rear Suspension of Lamborghini Lamborghini Diablo SE30 (1993-1995)

View All

Lamborghini Diablo SE30 (1993-1995) - Rear Suspension

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	WHT003355	NUT M12X1,25	WHT003355 NUT M12X1,25 DADO	-	8	Enquire
002	410407127A	BOLT	410407127A BOLT ECCENTRICO	-	8	Enquire
003	410407295D	WASHER	410407295D WASHER RONDELLA SP = 3 MM	-	1	Enquire
003	5133488	SHIM	5133488 SHIM RONDELLA SP= 1,5 MM	-	1	Enquire
003	410407295	1.0 MM ADJUSTMENT SHIM	410407295 1.0 MM ADJUSTMENT SHIM RONDELLA SP = 1 MM	-	1	Enquire
003	410407295C	2.5 MM ADJUSTMENT SHIM	410407295C 2.5 MM ADJUSTMENT SHIM RONDELLA SP = 2,5 MM	-	1	Enquire
003	410407295B	2.0 MM ADJUSTMENT SHIM	410407295B 2.0 MM ADJUSTMENT SHIM RONDELLA SP = 2 MM	-	1	Enquire
004	8921206	RESILIENT BUSHING	8921206 RESILIENT BUSHING BOCCOLA ELASTICA	-	8	Enquire
005	410407127A	BOLT	410407127A BOLT PERNO CON ECCENTRICO	-	8	Enquire
006	8200804	NUT M8	8200804 NUT M8 DADO	-	4	Enquire
007	5227297	BUSHING	5227297 BUSHING BOCCOLA X SNODO SFERICO	-	8	Enquire
008	5109714	BOOT	5109714 BOOT CAPPUCCIO	-	1	Enquire
009	5227298	BUSHING	5227298 BUSHING BOCC.RIDUZ.BARRA Dl TORSI	-	4	Enquire
010	417801931A	BALL JOINT	417801931A BALL JOINT GIUNTO SFERICO	-	2	Enquire
011	8201016	NUT	8201016 NUT DADO	-	2	Enquire
012	5209770	TIE ROD	5209770 TIE ROD TIRANTE	-	2	Enquire
013	8201014	NUT	8201014 NUT DADO	-	2	Enquire
014	5227295	BALL JOINT	5227295 BALL JOINT GIUNTO SFERICO	-	2	Enquire
015	8251702	PLUG	8251702 PLUG GHIERA	-	4	Enquire
016	8401708	WASHER	8401708 WASHER RONDELLA	-	4	Enquire
017	5233269	SHOCK ABSORBER	5233269 SHOCK ABSORBER AMMORTIZZATORE POSTERIORE	-	1	Enquire
018	WHT003355	NUT M12X1,25	WHT003355 NUT M12X1,25 DADO	-	8	Enquire
019	410512383	FLEXIBLE BUSHING	410512383 FLEXIBLE BUSHING	-	8	Enquire
020	8101259	SCREW	8101259 SCREW VITE	-	8	Enquire
021	410512385	RUBBER RING	410512385 RUBBER RING	-	8	Enquire
022	5235182	SPRING	5235182 SPRING MOLLA	-	4	Enquire
023	5135183	SPACER	5135183 SPACER DISTANZIALE	-	4	Enquire
024	5234841	LEFT LOWER ARM	5234841 LEFT LOWER ARM BRACCIO INFERIORE SX.	-	1	Enquire
024	5234842	RIGHT LOWER ARM	5234842 RIGHT LOWER ARM BRACCIO INFERIORE DX.	-	1	Enquire
025	5225207	RESILIENT BUSHING	5225207 RESILIENT BUSHING BOCCOLA ELASTICA	-	8	Enquire
026	8401710	WASHER	8401710 WASHER RONDELLA	-	24	Enquire
027	5225205	PIN	5225205 PIN PERNO FISS.BRACCIO SUP.	-	2	Enquire
028	5225908	RH UPPER SUSPENSION ARM	5225908 RH UPPER SUSPENSION ARM	-	1	Enquire
028	5225909	ARM	5225909 ARM BRACCIO SUPER.SINISTRO	-	1	Enquire
029	5225204	PIN	5225204 PIN PERNO	-	2	Enquire
030	8100810	SCREW	8100810 SCREW VITE	-	2	Enquire
