Lamborghini Diablo SE30 (1993-1995) - Windows

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	9415204	RIGHT FRAME	9415204 RIGHT FRAME CORNICE LATERALE DX	-	1	Enquire
002	9415107	FRONT GLASS	9415107 FRONT GLASS PARABREZZA	-	1	Enquire
003	9415200	TOP FRAME	9415200 TOP FRAME CORNICE SUPERIORE	-	1	Enquire
004	410845235	WINDSHIELD SPACER	410845235 WINDSHIELD SPACER	-	5	Enquire
005	9418100	REAR GLASS	9418100 REAR GLASS LUNOTTO	-	1	Enquire
006	9418103	GASKET	9418103 GASKET GUARNIZIONE LUNOTTO	-	1	Enquire
007	9421719	RIGHT PAD	9421719 RIGHT PAD TASSELLO DX	-	1	Enquire
007	9421720	LEFT PAD	9421720 LEFT PAD TASSELLO SX	-	1	Enquire
008	9421733	GASKET	9421733 GASKET GUARNIZIONE	-	2	Enquire
009	400845633	QUARTER WINDOW GLASS SHIM	400845633 QUARTER WINDOW GLASS SHIM DISTANZIALE	-	2	Enquire
010	70004149	RIGHT HAND GLASS	70004149 RIGHT HAND GLASS CRISTALLO LAT. DX FISSO	-	1	Enquire
010	70004150	LEFT HAND GLASS	70004150 LEFT HAND GLASS CRISTALLO LAT. SX FISSO	-	1	Enquire
011	9417107	LEFT FRAME	9417107 LEFT FRAME CORNICE SX	-	1	Enquire
011	9417106	RIGHT FRAME	9417106 RIGHT FRAME CORNICE DX	-	1	Enquire
012	9417103	LEFT FRAME	9417103 LEFT FRAME CORNICE SX	-	1	Enquire
012	9417102	RIGHT FRAME	9417102 RIGHT FRAME CORNICE DX	-	1	Enquire
013	410845626	SPACER	410845626 SPACER	-	2	Enquire
014	9417105	LEFT FRAME	9417105 LEFT FRAME CORNICE SX	-	1	Enquire
014	9417104	RIGHT FRAME	9417104 RIGHT FRAME CORNICE DX	-	1	Enquire
015	WHT003065	SCREW (2,9X16)	WHT003065 SCREW (2,9X16) VITE	-	6	Enquire
016	72010205	RHS GASKET	72010205 RHS GASKET	-	1	Enquire
016	72010206	LHS GASKET	72010206 LHS GASKET GUARNIZIONE GIROPORTA	-	1	Enquire
017	9421423	RIGHT LATERAL GLASS	9421423 RIGHT LATERAL GLASS CRISTALLO LATERALE DX	-	1	Enquire
017	9421424	LEFT LATERAL GLASS (Small Glass Only)	9421424 LEFT LATERAL GLASS (Small Glass Only) CRISTALLO LATERALE SX	-	1	Enquire
018	72001177	GASKET	72001177 GASKET	-	2	Enquire
019	8700211	BLACK SCREW	8700211 BLACK SCREW VITE	-	4	Enquire
020	9421718	PLATE	9421718 PLATE PIASTRINA	-	2	Enquire
021	9421708	RIGHT SUPPORT	9421708 RIGHT SUPPORT SUPPORTO DX	-	1	Enquire
021	9421709	LEFT SUPPORT	9421709 LEFT SUPPORT SUPPORTO SX	-	1	Enquire
022	9415205	LEFT FRAME	9415205 LEFT FRAME CORNICE LATERALE SX	-	1	Enquire
023	9415201	BOTTOM FRAME	9415201 BOTTOM FRAME CORNICE INFERIORE	-	1	Enquire
024	9415101	SPACER	9415101 SPACER DISTANZIALE	-	3	Enquire
