Adjustable Rear Anti Rool Bar of Lamborghini Lamborghini Diablo SE30 (1993-1995)

View All

Lamborghini Diablo SE30 (1993-1995) - Adjustable Rear Anti Rool Bar

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	5235374	BAR SELECTOR	5235374 BAR SELECTOR SELETTORE X COM. BARRA	$89.34	1
002	5235373	CONTROL LEVER	5235373 CONTROL LEVER LEVA X ALBER.COM. BARRA	$141.72	1
003	8700462	SCREW	8700462 SCREW VITE	$2.29	2
004	5235372	SHAFT	5235372 SHAFT ALBER.COM. BARRA STABILIZZ	$120.36	1
005	5235615	SUPPORT - SUPPORTO	5235615 SUPPORT - SUPPORTO O	$90.04	1
006	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$44.87	4
007	8700609	SCREW	8700609 SCREW VITE	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
008	5235319	TORSION BAR	5235319 TORSION BAR BARRA TORSIONE	$970.23	1
009	5234706	BUSHING	5234706 BUSHING BOCC.X BARRA STABILIZZ.	$173.06	2
010	8582701	RETAINING RING IN STOCK	8582701 RETAINING RING ANELLO RITEGNO IN STOCK	$2.33 MSRP: ~~7.03~~ (66.9% off)	1
011	5235324	BUSHING	5235324 BUSHING BOCC.X BRACCIO MOBILE	$207.19	2
012	5235321	MOBILE ARM	5235321 MOBILE ARM BRACCIO MOBILE X BARRA	$348.64	1
013	WHT001187	WASHER IN STOCK	WHT001187 WASHER RONDELLA IN STOCK	$0.82 MSRP: ~~7.26~~ (88.7% off)	2
014	8100519	SCREW	8100519 SCREW VITE	$2.05	1
015	N0211963	NUT IN STOCK	N0211963 NUT DADO IN STOCK	$0.76	1
016	1333868	BALL JOINT	1333868 BALL JOINT GIUNTO SFERICO	$159.95	1
017	N01020717	SCREW M5X12 IN STOCK	N01020717 SCREW M5X12 VITE IN STOCK	$0.67 MSRP: ~~7.31~~ (90.8% off)	2
018	N0211963	NUT IN STOCK	N0211963 NUT DADO IN STOCK	$0.76	2
019	5234703	RETAINER	5234703 RETAINER CAVALLOTTO	$230.17	2
020	8830908	STRAP	8830908 STRAP FASCETTA	$12.97	3
021	5235586	CABLE	5235586 CABLE CAVO METALLICO	$704.72	1
022	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.04	1
023	5235322	MOBILE ARM	5235322 MOBILE ARM BRACCIO MOBILE X BARRA	$1,941.70	1
024	5235323	BUSHING	5235323 BUSHING BOCC.X BRACCIO REGOL	$37.10	1
025	8700614	SCREW	8700614 SCREW VITE	$0.27	1
026	5235371	SUPPORT	5235371 SUPPORT SUPP.X ALB.COM. BARRA STAB	$120.36	1
027	8200408	NUT	8200408 NUT DADO	$0.16	3
028	5235587	SPRING	5235587 SPRING MOLLA	$39.00	1
