Crankgears of Lamborghini Lamborghini Diablo SE30 (1993-1995)

View All

Lamborghini Diablo SE30 (1993-1995) - Crankgears

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	7M109381	RETAINING RING	7M109381 RETAINING RING ANELLO RITEGNO	-	1	Enquire
002	1434827	PISTON - PISTONE COMPLETO	1434827 PISTON - PISTONE COMPLETO E COMPLETO	-	12	Enquire
003	7M107311	PISTON RING	7M107311 PISTON RING SEGMENTO	-	12	Enquire
004	7M107313	PISTON RING	7M107313 PISTON RING SEGMENTO	-	12	Enquire
005	7M107321	PISTON RING	7M107321 PISTON RING SEGMENTO	-	12	Enquire
006	1430768	BUSHING	1430768 BUSHING BOCCOLA	-	12	Enquire
007	1430537	RETAINER RING	1430537 RETAINER RING ANELLO RITEGNO	-	24	Enquire
008	1430536	PISTON PIN	1430536 PISTON PIN SPINOTTO	-	12	Enquire
009	410109264	BEARING	410109264 BEARING CUSCINETTO	-	1	Enquire
010	7M105701	Brass	7M105701 Brass BRONZINA	-	24	Enquire
011	8900308	DOWEL	8900308 DOWEL GRAND	-	24	Enquire
012	1422563	CON. ROD BOLT	1422563 CON. ROD BOLT BULLONE PER BIELLA	-	24	Enquire
013	1429577	CON ROD ASSY	1429577 CON ROD ASSY	-	12	Enquire
014	423400300	CRANKSHAFT	423400300 CRANKSHAFT	-	1	Enquire
015	8860506	KEY	8860506 KEY CHIAVE Dl FERMO	-	1	Enquire
016	7M105532	THRUST WASHER (PRICE EACH)	7M105532 THRUST WASHER (PRICE EACH) use:2x 07M105531A & 2x 07M105532	-	2	Enquire
017	7M105707	HALF BEARING	7M105707 HALF BEARING SEMICUSCINETTO	-	2	Enquire
018	7M105531A	AXIAL HALF BEARING	7M105531A AXIAL HALF BEARING SEMICUSCINETTO ASSIALE	-	2	Enquire
019	7M105707A	HALF BEARING	7M105707A HALF BEARING SEMICUSCINETTO	-	2	Enquire
020	7M105707B	HALF BEARING	7M105707B HALF BEARING SEMICUSCINETTO	-	5	Enquire
021	7M105707C	HALF BEARING	7M105707C HALF BEARING SEMICUSCINETTO	-	5	Enquire
