Lamborghini Diablo (1990-1998) - Front Brakes (Valid for October 1991 Version)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	8836302	CLAMP	8836302 CLAMP (Valid for October 1991 version) FASCETTA	-	6	Enquire
002	9453128	FLEX. HOSE	9453128 FLEX. HOSE (Valid for October 1991 version) TUBO FLESSIBILE	-	2	Enquire
003	N01020717	SCREW M5X12	N01020717 SCREW M5X12 (Valid for October 1991 version) VITE	-	6	Enquire
004	8410508	WASHER	8410508 WASHER (Valid for October 1991 version) RONDELLA	-	6	Enquire
005	8400509	WASHER	8400509 WASHER (Valid for October 1991 version) RONDELLA	-	6	Enquire
006	3129881	FRONT BRAKES PIPE	3129881 FRONT BRAKES PIPE (Valid for October 1991 version) TUBO FRENI ANTERIORI	-	1	Enquire
007	3129778	SCREW	3129778 SCREW (Valid for October 1991 version) VITE	-	2	Enquire
008	3113905	WASHER	3113905 WASHER (Valid for October 1991 version) RONDELLA	-	2	Enquire
009	3113904	CONNECTION	3113904 CONNECTION (Valid for October 1991 version) RACCORDO	-	2	Enquire
010	3113906	WASHER	3113906 WASHER (Valid for October 1991 version) RONDELLA	-	4	Enquire
011	3129777	SPACER	3129777 SPACER (Valid for October 1991 version) DISTANZIALE	-	2	Enquire
012	8101219	SCREW	8101219 SCREW (Valid for October 1991 version) VITE	-	4	Enquire
013	8411303	WASHER	8411303 WASHER (Valid for October 1991 version) RONDELLA	-	4	Enquire
014	3230723	SHIM	3230723 SHIM (Valid for October 1991 version) RONDELLA SP. 0,4 MM	-	1	Enquire
014	3230722	WASHER	3230722 WASHER (Valid for October 1991 version) RONDELLA SP. 0,3 MM	-	1	Enquire
014	3230721	SHIM	3230721 SHIM (Valid for October 1991 version) RONDELLA SP. 0,2 MM	-	1	Enquire
014	3230719	SHIM	3230719 SHIM (Valid for October 1991 version) RONDELLA SP. 0,05 MM	-	1	Enquire
014	3230720	SHIM	3230720 SHIM (Valid for October 1991 version) RONDELLA SP. 0,1 MM	-	1	Enquire
014	3230727	SHIM	3230727 SHIM (Valid for October 1991 version) RONDELLA SP. 1 MM	-	1	Enquire
014	3230724	SHIM	3230724 SHIM (Valid for October 1991 version) RONDELLA SP. 0,5 MM	-	1	Enquire
014	3230726	SHIM	3230726 SHIM (Valid for October 1991 version) RONDELLA SP. 0,8 MM	-	1	Enquire
014	3230725	SHIM	3230725 SHIM (Valid for October 1991 version) RONDELLA SP. 0,6 MM	-	1	Enquire
015	3132826	LEFT MUDGUARDS	3132826 LEFT MUDGUARDS (Valid for October 1991 version) PARASPRUZZl SINISTRO	-	1	Enquire
015	3132825	RIGHT MUDGUARDS	3132825 RIGHT MUDGUARDS (Valid for October 1991 version) PARASPRUZZI DESTRO	-	1	Enquire
016	3129435	BRAKE CALIPER	3129435 BRAKE CALIPER (Valid for October 1991 version) PINZA FRENI SINISTRA CON PASIGLIE	-	1	Enquire
016	3129436	BRAKE CALIPER CPL	3129436 BRAKE CALIPER CPL (Valid for October 1991 version) PINZA FRENI DESTRA CON PASTIGLIE	-	1	Enquire
017	3135292	FRONT BRAKE PADS	3135292 FRONT BRAKE PADS PRICE EACH PAD	-	4	Enquire
018	N01029315	SCREW (FROM VIN 5LA01545)	N01029315 SCREW (FROM VIN 5LA01545) (Valid for October 1991 version) VITE	-	6	Enquire
019	3126969	BRAKE DISC	3126969 BRAKE DISC (Valid for October 1991 version)DISCO FRENO ANTERIORE	-	2	Enquire
