Name: CRANKCASE
Rating: 4.9 (1 reviews)

CRANKCASE of Ferrari Ferrari Roma Spider Europe RH

View All

Ferrari Roma Spider Europe RH - CRANKCASE

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	764321	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	$5,767.02	To Order

Photo	Part No	Description	Price (each)	Stock
	271598	GASKET	$38.49	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	$0.32	To Order

Photo	Part No	Description	Price (each)	Stock
	271810	CYLINDER SLEEVE	$304.39	To Order

Photo	Part No	Description	Price (each)	Stock
	294153	GASKET	$3.40	To Order

Photo	Part No	Description	Price (each)	Stock
	270464	STUD BOLT	$30.47	To Order

Photo	Part No	Description	Price (each)	Stock
	185360	CENTERING DOWEL	$2.97	To Order

Photo	Part No	Description	Price (each)	Stock
	271564	STUD BOLT	$30.08	To Order

Photo	Part No	Description	Price (each)	Stock
	278119	STUD BOLT	$22.45	To Order

Photo	Part No	Description	Price (each)	Stock
	307477	THREADED PLUG	$3.84	To Order

Photo	Part No	Description	Price (each)	Stock
	10263460	COPPER GASKET D.28-22.3 X 1.5	$0.37	To Order

Photo	Part No	Description	Price (each)	Stock
	294614	CHECK VALVE	$38.69	To Order

Photo	Part No	Description	Price (each)	Stock
	311001	CENTERING DOWEL	$3.13	To Order

Photo	Part No	Description	Price (each)	Stock
	282753	THREADED PLUG	$6.66	To Order

Photo	Part No	Description	Price (each)	Stock
	282755	THREADED PLUG	$2.14	To Order

Photo	Part No	Description	Price (each)	Stock
	298858	PISTON COOLING NOZZLE ASSEMBLY	$41.70	To Order

Photo	Part No	Description	Price (each)	Stock
	298859	PISTON COOLING NOZZLE ASSEMBLY	$28.87	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	$0.32	To Order

Photo	Part No	Description	Price (each)	Stock
	339298	GASKET	$56.14	To Order

Photo	Part No	Description	Price (each)	Stock
	339289	GASKET	$52.94	To Order

Photo	Part No	Description	Price (each)	Stock
	278120	STUD BOLT	$25.79	To Order

Photo	Part No	Description	Price (each)	Stock
	288133	DRIVE JOINT	$146.00	To Order

Photo	Part No	Description	Price (each)	Stock
	11060276	SEEGER RING	$0.45	To Order

Photo	Part No	Description	Price (each)	Stock
	247049	BEARING	$53.41	To Order

Photo	Part No	Description	Price (each)	Stock
	11066876	SEEGER RING	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	102725	CENTERING DOWEL	$1.17	To Order

Photo	Part No	Description	Price (each)	Stock
	255138	BLOW-BY VALVE ASSEMBLY	$117.52	To Order

Photo	Part No	Description	Price (each)	Stock
	14303123	SCREW	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	291078	THREADED PLUG	$2.43	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	764321	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	764321 CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	$5,767.02	1
0002	271598	GASKET	271598 GASKET Also included in engine gasket set	$38.49	1
0003	231620	SCREW	231620 SCREW M6 X 25	$0.32 MSRP: ~~0.35~~ (8.6% off)	13
0004	271810	CYLINDER SLEEVE	271810 CYLINDER SLEEVE	$304.39	8
0005	294153	GASKET	294153 GASKET Also included in engine gasket set	$3.40	24
0006	270464	STUD BOLT	270464 STUD BOLT	$30.47	18
0007	185360	CENTERING DOWEL	185360 CENTERING DOWEL	$2.97	4
0008	271564	STUD BOLT	271564 STUD BOLT	$30.08	2
0009	278119	STUD BOLT	278119 STUD BOLT	$22.45	6
0010	307477	THREADED PLUG	307477 THREADED PLUG	$3.84	2
0011	10263460	COPPER GASKET D.28-22.3 X 1.5	10263460 COPPER GASKET D.28-22.3 X 1.5 Also included in engine gasket set	$0.37 MSRP: ~~1.00~~ (63% off)	2
0012	294614	CHECK VALVE	294614 CHECK VALVE	$38.69	1
0013	311001	CENTERING DOWEL	311001 CENTERING DOWEL	$3.13	2
0014	282753	THREADED PLUG	282753 THREADED PLUG	$6.66	2
0015	282755	THREADED PLUG	282755 THREADED PLUG D. 10 X 1.25	$2.14	2
0016	298858	PISTON COOLING NOZZLE ASSEMBLY	298858 PISTON COOLING NOZZLE ASSEMBLY	$41.70	4
0017	298859	PISTON COOLING NOZZLE ASSEMBLY	298859 PISTON COOLING NOZZLE ASSEMBLY	$28.87	8
0018	231620	SCREW	231620 SCREW M6 X 30	$0.32 MSRP: ~~0.35~~ (8.6% off)	1
0019	339298	GASKET	339298 GASKET Also included in engine gasket set	$56.14	1
0020	339289	GASKET	339289 GASKET Also included in engine gasket set	$52.94	1
0021	278120	STUD BOLT	278120 STUD BOLT	$25.79	2
0022	288133	DRIVE JOINT	288133 DRIVE JOINT	$146.00	1
0023	11060276	SEEGER RING	11060276 SEEGER RING	$0.45 MSRP: ~~1.75~~ (74.3% off)	1
0024	247049	BEARING	247049 BEARING	$53.41	1
0025	11066876	SEEGER RING	11066876 SEEGER RING	$0.06 MSRP: ~~0.35~~ (82.9% off)	1
0026	102725	CENTERING DOWEL	102725 CENTERING DOWEL	$1.17 MSRP: ~~2.25~~ (48% off)	2
0027	255138	BLOW-BY VALVE ASSEMBLY	255138 BLOW-BY VALVE ASSEMBLY	$117.52	4
0028	14303123	SCREW	14303123 SCREW M4 X 14	$0.06	8
0029	291078	THREADED PLUG	291078 THREADED PLUG M12 X 11	$2.43	2
