Ferrari Purosangue USA - PTU SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	943858	POWER TAKE OFF UNIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14308734	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11190574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307934	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	942844	FASTENER NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	925715	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	955262	DECOUPLING GEAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307834	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10441590	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10441290	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	880041	Allen Head Bolt M6 X 26	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	897379	RUBBER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	776344	COMPL. OIL PIPE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	278889	RUBBER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	336484	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239829	VIBRATION DAMPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	858323	PTU OIL RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	277070	COMPL. ELECTRIC FAN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	749792	PTU RADIATOR MOUNTING BRACKET	Enquire	To Order
	957554	LOWER PTU RADIATOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	847301	TIE-ROD ON PTU OIL RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	841863	OIL DELIVERY PIPE FROM PTU TO RADIATOR	Enquire	To Order
	998242	OIL DELIVERY PIPE FROM PTU TO RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	841862	OIL RETURN PIPE FROM PTU TO RADIATOR	Enquire	To Order
	998241	OIL RETURN PIPE FROM PTU TO RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	940339	COMPL. MPU TANK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	919935	MPU TANK PIPE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	307674	RADIATOR MOUNTING BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13577724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	128200050	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282756	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	880041	Allen Head Bolt M6 X 26	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12647878	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291225	P clip Bracket With Sheath	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254644	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	303339	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	912593	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	320600	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	307674	RADIATOR MOUNTING BUSH	Enquire	To Order
	290935	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	969955	PTU PIPE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	897379	RUBBER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	943858	POWER TAKE OFF UNIT	943858 POWER TAKE OFF UNIT	-	1	Enquire
0002	14308734	SCREW	14308734 SCREW M10 X 1.25 X 100	-	2	Enquire
0003	11190574	WASHER	11190574 WASHER	-	7	Enquire
0004	14307934	SCREW	14307934 SCREW M10 X 1.25 X 50	-	3	Enquire
0005	942844	FASTENER NUT	942844 FASTENER NUT	-	1	Enquire
0006	925715	O-RING	925715 O-RING	-	1	Enquire
0007	955262	DECOUPLING GEAR	955262 DECOUPLING GEAR	-	1	Enquire
0008	14307834	SCREW	14307834 SCREW M10 X 1.25 X 45	-	2	Enquire
0009	10441590	BRACKET WITH SHEATH	10441590 BRACKET WITH SHEATH	-	6	Enquire
0010	10441290	BRACKET WITH SHEATH	10441290 BRACKET WITH SHEATH D. 10	-	5	Enquire
0011	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 14	-	2	Enquire
0012	880041	Allen Head Bolt M6 X 26	880041 Allen Head Bolt M6 X 26 M6 X 20	-	3	Enquire
0013	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	7	Enquire
0014	897379	RUBBER BUSHING	897379 RUBBER BUSHING	-	3	Enquire
0015	776344	COMPL. OIL PIPE MOUNTING BRACKET	776344 COMPL. OIL PIPE MOUNTING BRACKET	-	1	Enquire
0016	278889	RUBBER RING	278889 RUBBER RING	-	1	Enquire
0017	336484	CLAMP	336484 CLAMP	-	2	Enquire
0018	239829	VIBRATION DAMPER	239829 VIBRATION DAMPER	-	4	Enquire
0019	858323	PTU OIL RADIATOR	858323 PTU OIL RADIATOR	-	1	Enquire
0020	277070	COMPL. ELECTRIC FAN	277070 COMPL. ELECTRIC FAN	-	1	Enquire
0021	749792	PTU RADIATOR MOUNTING BRACKET	749792 PTU RADIATOR MOUNTING BRACKET Applies until depletion	-	1	Enquire
0021	957554	LOWER PTU RADIATOR BRACKET	957554 LOWER PTU RADIATOR BRACKET For vehicles up to Ass.ly No. 209191, also order bush 290935 ref. 39; Applicable after depletion of 749792	-	1	Enquire
0022	847301	TIE-ROD ON PTU OIL RADIATOR	847301 TIE-ROD ON PTU OIL RADIATOR	-	1	Enquire
0023	841863	OIL DELIVERY PIPE FROM PTU TO RADIATOR	841863 OIL DELIVERY PIPE FROM PTU TO RADIATOR Applies until depletion	-	1	Enquire
0023	998242	OIL DELIVERY PIPE FROM PTU TO RADIATOR	998242 OIL DELIVERY PIPE FROM PTU TO RADIATOR Applicable after depletion of 841863	-	1	Enquire
0024	841862	OIL RETURN PIPE FROM PTU TO RADIATOR	841862 OIL RETURN PIPE FROM PTU TO RADIATOR Applies until depletion	-	1	Enquire
0024	998241	OIL RETURN PIPE FROM PTU TO RADIATOR	998241 OIL RETURN PIPE FROM PTU TO RADIATOR Applicable after depletion of 841862	-	1	Enquire
0025	940339	COMPL. MPU TANK	940339 COMPL. MPU TANK	-	1	Enquire
0026	919935	MPU TANK PIPE MOUNTING BRACKET	919935 MPU TANK PIPE MOUNTING BRACKET	-	1	Enquire
0027	307674	RADIATOR MOUNTING BUSH	307674 RADIATOR MOUNTING BUSH	-	1	Enquire
0028	13577724	WASHER	13577724 WASHER	-	8	Enquire
0029	128200050	NUT	128200050 NUT	-	4	Enquire
0030	282756	THREADED PLUG	282756 THREADED PLUG	-	1	Enquire
0031	880041	Allen Head Bolt M6 X 26	880041 Allen Head Bolt M6 X 26 M6 X 20	-	5	Enquire
0032	12647878	WASHER	12647878 WASHER	-	1	Enquire
0033	291225	P clip Bracket With Sheath	291225 P clip Bracket With Sheath	-	4	Enquire
0034	254644	O-RING	254644 O-RING	-	4	Enquire
0035	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 20	-	6	Enquire
0036	303339	CLIP	303339 CLIP	-	1	Enquire
0037	912593	CLIP	912593 CLIP	-	1	Enquire
0038	320600	CLIP	320600 CLIP	-	1	Enquire
0039	307674	RADIATOR MOUNTING BUSH	307674 RADIATOR MOUNTING BUSH	-	2	Enquire
0039	290935	BUSH	290935 BUSH	-	2	Enquire
0040	969955	PTU PIPE MOUNTING BRACKET	969955 PTU PIPE MOUNTING BRACKET	-	1	Enquire
0041	14040614	NUT	14040614 NUT	-	6	Enquire
0042	897379	RUBBER BUSHING	897379 RUBBER BUSHING	-	3	Enquire
0043	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 18	-	7	Enquire
0043	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 18	-	3	Enquire
