Rear Suspension - Arms

Ferrari GTC4Lusso T

Find Your Part

Ferrari GTC4Lusso T - REAR SUSPENSION - ARMS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
259687 REAR UPPER ARM Enquire IN STOCK
Photo Part No Description Price (each) Stock
911176 LH LOWER REAR ARM Enquire ARRIVING SOON
329244 COMPL. LOWER RH REAR ARM Enquire To Order
Photo Part No Description Price (each) Stock
343376 BALL JOINT Enquire IN STOCK
Photo Part No Description Price (each) Stock
238656 SPECIAL SCREW Enquire IN STOCK
Photo Part No Description Price (each) Stock
238063 NUT Enquire IN STOCK
Photo Part No Description Price (each) Stock
259688 ANTI-ROTATION LINKAGE Enquire ARRIVING SOON
Photo Part No Description Price (each) Stock
222956 COMPENSATOR RING Enquire IN STOCK
Photo Part No Description Price (each) Stock
238258 SCREW Enquire IN STOCK
Photo Part No Description Price (each) Stock
15541434 SCREW Enquire IN STOCK
Photo Part No Description Price (each) Stock
12643778 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
203666 NUT M12 Enquire IN STOCK
Photo Part No Description Price (each) Stock
330990 COMPL. LH ACTUATOR Enquire To Order
330992 COMPL. RH ACTUATOR Enquire To Order
Photo Part No Description Price (each) Stock
15541434 SCREW Enquire IN STOCK
Photo Part No Description Price (each) Stock
203666 NUT M12 Enquire IN STOCK
Photo Part No Description Price (each) Stock
12643778 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
12574521 Nyloc Nut Enquire IN STOCK
Photo Part No Description Price (each) Stock
126648 WASHER D.10.5-21 X 2 Enquire IN STOCK
Photo Part No Description Price (each) Stock
264528 THREADED ROD 10 X 1.25 Enquire ARRIVING SOON
Photo Part No Description Price (each) Stock
262541 ADJUSTER SHIM Enquire IN STOCK
262542 ADJUSTER SHIM Enquire IN STOCK
262543 ADJUSTER SHIM Enquire To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
12646821 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
294851 RH HUB CARRIER Enquire IN STOCK
294850 LH HUB CARRIER Enquire IN STOCK
Photo Part No Description Price (each) Stock
269415 ABS SENSOR Enquire IN STOCK
Photo Part No Description Price (each) Stock
251744 TRIPLE CLIP Enquire IN STOCK
Photo Part No Description Price (each) Stock
104030 NYLOC NUT M8 X 1.25 X 9.5 Enquire IN STOCK
Photo Part No Description Price (each) Stock
14496524 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
13578321 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
302406 THREADED ROD Enquire To Order
Photo Part No Description Price (each) Stock
250657 SCREW M6 X 14 Enquire IN STOCK
Photo Part No Description Price (each) Stock
16286121 SCREW Enquire IN STOCK
Photo Part No Description Price (each) Stock
294300 LH BRACKET Enquire To Order
294301 RH BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
291678 CONNECTOR RETAINER CLIP Enquire To Order
Photo Part No Description Price (each) Stock
303508 CLIP Enquire To Order
View All
REAR SUSPENSION - ARMS of Ferrari Ferrari GTC4Lusso T Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 259687
REAR UPPER ARM
IN STOCK 		- 2 Enquire
2 911176
LH LOWER REAR ARM
ARRIVING SOON 		- 1 Enquire
2 329244
COMPL. LOWER RH REAR ARM 		- 1 Enquire
3 343376
BALL JOINT
IN STOCK 		- 2 Enquire
4 238656
SPECIAL SCREW
IN STOCK 		- 2 Enquire
5 238063
NUT
IN STOCK 		- 2 Enquire
6 259688
ANTI-ROTATION LINKAGE
ARRIVING SOON 		- 2 Enquire
7 222956
COMPENSATOR RING
IN STOCK 		- 2 Enquire
8 238258
SCREW
M12 X 1.25 X 75
IN STOCK 		- 2 Enquire
9 15541434
SCREW
M12 X 1.25 X 80
IN STOCK 		- 2 Enquire
10 12643778
WASHER 		- 4 Enquire
11 203666
NUT M12
IN STOCK 		- 2 Enquire
12 330990
COMPL. LH ACTUATOR 		- 1 Enquire
12 330992
COMPL. RH ACTUATOR 		- 1 Enquire
13 15541434
SCREW
M12 X 1.25 X 80
IN STOCK 		- 2 Enquire
14 203666
NUT M12
IN STOCK 		- 2 Enquire
15 12643778
WASHER 		- 4 Enquire
16 12574521
Nyloc Nut
IN STOCK 		- 12 Enquire
17 126648
WASHER D.10.5-21 X 2
IN STOCK 		- 12 Enquire
18 264528
THREADED ROD 10 X 1.25
ARRIVING SOON 		- 12 Enquire
19 262541
ADJUSTER SHIM
Th. 3 mm
IN STOCK 		- 4 Enquire
19 262542
ADJUSTER SHIM
Th. 3.5 mm
IN STOCK 		- 4 Enquire
19 262543
ADJUSTER SHIM
Th. 4 mm 		- 4 Enquire
19 262544
ADJUSTER SHIM
Th. 0.5 mm
IN STOCK 		- 4 Enquire
19 262545
ADJUSTER SHIM
Th. 1 mm 		- 4 Enquire
19 262546
ADJUSTER SHIM
Th. 1.5 mm
IN STOCK 		- 4 Enquire
19 262539
ADJUSTER SHIM
Th. 2 mm 		- 4 Enquire
19 262540
ADJUSTER SHIM
Th. 2.5 mm
IN STOCK 		- 4 Enquire
20 12646821
WASHER
IN STOCK 		- 4 Enquire
21 294851
RH HUB CARRIER
IN STOCK 		- 1 Enquire
21 294850
LH HUB CARRIER
IN STOCK 		- 1 Enquire
22 269415
ABS SENSOR
IN STOCK 		- 2 Enquire
23 251744
TRIPLE CLIP
IN STOCK 		- 4 Enquire
24 104030
NYLOC NUT M8 X 1.25 X 9.5
IN STOCK 		- 4 Enquire
25 14496524
WASHER
IN STOCK 		- 4 Enquire
26 13578321
WASHER
IN STOCK 		- 4 Enquire
27 302406
THREADED ROD 		- 4 Enquire
28 250657
SCREW M6 X 14
M6 X 14
IN STOCK 		- 2 Enquire
29 16286121
SCREW
M6 X 18
IN STOCK 		- 2 Enquire
30 294300
LH BRACKET 		- 1 Enquire
30 294301
RH BRACKET 		- 1 Enquire
31 291678
CONNECTOR RETAINER CLIP 		- 4 Enquire
32 303508
CLIP 		- 2 Enquire
