REAR ACTIVE AERO of Ferrari Ferrari 488 Pista Europe

View All

Ferrari 488 Pista Europe - REAR ACTIVE AERO

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	748053	ACTUATOR COMPL. WITH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85708700	CENTRE SHAFT SECTION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85708800	LATERAL SHAFT SECTION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85708900	SHAFT MOUNT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85709000	CENTRE RETURN SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310109	RH RETURN SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310110	LH RETURN SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	318981	HATCH ACTUATOR LINK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	318983	SHAFT DRIVE LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	328330	CONTROL CAM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	329318	FLEXIBLE SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	301785	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	301909	SELF-LOCKING NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	306350	SAFETY CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	306757	UPPER LINK PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85709300	CENTRAL SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85709400	LATERAL SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85709700	LATERAL LINK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85711700	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85711800	DRIVE PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85712100	LOWER LINK PINS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85712200	BUSH FOR LINK PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	87804600	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10815787	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305324	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	309215	HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order
	85833700	SCREW	Enquire	To Order
	85833700	SCREW	Enquire	To Order

...and 2 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	748053	ACTUATOR COMPL. WITH BRACKET	748053 ACTUATOR COMPL. WITH BRACKET	-	1	Enquire
0002	85708700	CENTRE SHAFT SECTION	85708700 CENTRE SHAFT SECTION	-	1	Enquire
0003	85708800	LATERAL SHAFT SECTION	85708800 LATERAL SHAFT SECTION	-	2	Enquire
0004	85708900	SHAFT MOUNT	85708900 SHAFT MOUNT	-	6	Enquire
0005	85709000	CENTRE RETURN SPRING	85709000 CENTRE RETURN SPRING	-	1	Enquire
0006	310109	RH RETURN SPRING	310109 RH RETURN SPRING	-	1	Enquire
0007	310110	LH RETURN SPRING	310110 LH RETURN SPRING	-	1	Enquire
0008	318981	HATCH ACTUATOR LINK	318981 HATCH ACTUATOR LINK	-	4	Enquire
0009	318983	SHAFT DRIVE LEVER	318983 SHAFT DRIVE LEVER	-	1	Enquire
0010	328330	CONTROL CAM	328330 CONTROL CAM	-	4	Enquire
0011	329318	FLEXIBLE SHAFT	329318 FLEXIBLE SHAFT	-	2	Enquire
0012	231620	SCREW	231620 SCREW M6 X 30	-	1	Enquire
0013	301785	SCREW	301785 SCREW M5 X 40	-	12	Enquire
0014	301909	SELF-LOCKING NUT	301909 SELF-LOCKING NUT	-	1	Enquire
0015	306350	SAFETY CLIP	306350 SAFETY CLIP	-	8	Enquire
0016	306757	UPPER LINK PIN	306757 UPPER LINK PIN	-	4	Enquire
0017	85709300	CENTRAL SPACER	85709300 CENTRAL SPACER	-	1	Enquire
0018	85709400	LATERAL SPACER	85709400 LATERAL SPACER	-	2	Enquire
0019	85709700	LATERAL LINK	85709700 LATERAL LINK	-	4	Enquire
0020	85711700	BUSH	85711700 BUSH	-	8	Enquire
0021	85711800	DRIVE PIN	85711800 DRIVE PIN	-	4	Enquire
0022	85712100	LOWER LINK PINS	85712100 LOWER LINK PINS	-	4	Enquire
0023	85712200	BUSH FOR LINK PIN	85712200 BUSH FOR LINK PIN	-	8	Enquire
0024	87804600	BUSH	87804600 BUSH	-	8	Enquire
0025	10815787	CLAMP	10815787 CLAMP	-	2	Enquire
0026	14305324	SCREW	14305324 SCREW M6 X 20	-	3	Enquire
0027	12643724	WASHER	12643724 WASHER	-	3	Enquire
0028	309215	HEAT SHIELD	309215 HEAT SHIELD	-	1	Enquire
0029	85833700	SCREW	85833700 SCREW Version for rear diffuser in naked weave carbon; M5 X 14	-	2	Enquire
0029	85833700	SCREW	85833700 SCREW M5 X 10	-	2	Enquire
0029	85833700	SCREW	85833700 SCREW M5 X 8	-	2	Enquire
0029	85833700	SCREW	85833700 SCREW M5 X 14	-	2	Enquire
0029	85833700	SCREW	85833700 SCREW M5 X 8	-	2	Enquire
