POWER STEERING SYSTEM of Ferrari Ferrari 458 Italia

View All

Ferrari 458 Italia - POWER STEERING SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	244010	BRAKE SERVO WITH PUMP LHD	Enquire	To Order
	248907	BRAKE SERVO COMPL. WITH PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601374	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12578211	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	250733	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	956155	BRAKE FLUID RESERVOIR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	238606	RUBBER PIPE	Enquire	To Order
	262569	RUBBER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	238607	RUBBER PIPE	Enquire	To Order
	262570	RUBBER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257804	PIPE WITH KAISER VALVE	Enquire	To Order
	257804	PIPE WITH KAISER VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262205	CONNECTOR PIPE	Enquire	To Order
	254197	CONNECTOR PIPE	Enquire	To Order
	262205	CONNECTOR PIPE	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	13432070	HOSE COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262432	UNDERFLOOR PIPE	Enquire	To Order
	262432	UNDERFLOOR PIPE	Enquire	To Order
	251446	UNDERFLOOR PIPE	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	262431	COMPL. FRONT VACUUM PIPE	Enquire	To Order
	275505	COMPL. FRONT VACUUM PIPE	Enquire	To Order
	273670	COMPL. FRONT VACUUM PIPE	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	258711	CLIP	Enquire	To Order
	258711	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291579	COMPL. KAISER PIPE MOUNTING BRACKET	Enquire	To Order
	291579	COMPL. KAISER PIPE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	268340	BRACKET	Enquire	To Order
	268340	BRACKET	Enquire	To Order
	258736	BRACKET	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	140130	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13432070	HOSE COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262568	COMPL. BRAKE FLUID RESERVOIR	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	244010	BRAKE SERVO WITH PUMP LHD	244010 BRAKE SERVO WITH PUMP LHD Not for GD	-	1	Enquire
1	248907	BRAKE SERVO COMPL. WITH PUMP	248907 BRAKE SERVO COMPL. WITH PUMP Applicable for GD	-	1	Enquire
2	12601374	WASHER	12601374 WASHER	-	4	Enquire
3	12578211	NUT	12578211 NUT	-	4	Enquire
4	250733	CLIP	250733 CLIP	-	1	Enquire
5	956155	BRAKE FLUID RESERVOIR	956155 BRAKE FLUID RESERVOIR	-	1	Enquire
6	238606	RUBBER PIPE	238606 RUBBER PIPE Not for GD	-	1	Enquire
6	262569	RUBBER PIPE	262569 RUBBER PIPE Applicable for GD	-	1	Enquire
7	238607	RUBBER PIPE	238607 RUBBER PIPE Not for GD	-	1	Enquire
7	262570	RUBBER PIPE	262570 RUBBER PIPE Applicable for GD	-	1	Enquire
8	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
9	257804	PIPE WITH KAISER VALVE	257804 PIPE WITH KAISER VALVE Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
9	257804	PIPE WITH KAISER VALVE	257804 PIPE WITH KAISER VALVE Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
10	262205	CONNECTOR PIPE	262205 CONNECTOR PIPE From start of production; Not for EU GS, GOLFO	-	1	Enquire
10	254197	CONNECTOR PIPE	254197 CONNECTOR PIPE Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
10	262205	CONNECTOR PIPE	262205 CONNECTOR PIPE Applicable for EU GS; Applicable from Ass. No. 90802	-	1	Enquire
10	262205	CONNECTOR PIPE	262205 CONNECTOR PIPE Applicable for GOLFO; Applicable from Ass. No. 91119	-	1	Enquire
10	254197	CONNECTOR PIPE	254197 CONNECTOR PIPE Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
11	13432070	HOSE COLLAR	13432070 HOSE COLLAR D. 15.7	-	3	Enquire
12	262432	UNDERFLOOR PIPE	262432 UNDERFLOOR PIPE Applicable for GOLFO; Applicable from Ass. No. 91119	-	1	Enquire
12	262432	UNDERFLOOR PIPE	262432 UNDERFLOOR PIPE From start of production; Not for EU GS, GOLFO	-	1	Enquire
12	251446	UNDERFLOOR PIPE	251446 UNDERFLOOR PIPE Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
12	262432	UNDERFLOOR PIPE	262432 UNDERFLOOR PIPE Applicable for EU GS; Applicable from Ass. No. 90802	-	1	Enquire
12	251446	UNDERFLOOR PIPE	251446 UNDERFLOOR PIPE Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
13	262431	COMPL. FRONT VACUUM PIPE	262431 COMPL. FRONT VACUUM PIPE Not for HELE; Applicable for GD	-	1	Enquire
13	275505	COMPL. FRONT VACUUM PIPE	275505 COMPL. FRONT VACUUM PIPE Applicable for HELE; Applicable for GD; Applicable from Ass. No. 97061	-	1	Enquire
13	273670	COMPL. FRONT VACUUM PIPE	273670 COMPL. FRONT VACUUM PIPE Applicable for HELE; Not for GD; Applicable from Ass. No. 97061	-	1	Enquire
13	263409	COMPL. FRONT VACUUM PIPE	263409 COMPL. FRONT VACUUM PIPE Not for HELE; Applicable for GOLFO; Applicable from Ass. No. 91119	-	1	Enquire
13	263409	COMPL. FRONT VACUUM PIPE	263409 COMPL. FRONT VACUUM PIPE From start of production; Not for HELE; Not for EU GS, GOLFO, GD	-	1	Enquire
13	238292	COMPL. FRONT VACUUM PIPE	238292 COMPL. FRONT VACUUM PIPE Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
13	263409	COMPL. FRONT VACUUM PIPE	263409 COMPL. FRONT VACUUM PIPE Not for HELE; Applicable for EU GS; Applicable from Ass. No. 90802	-	1	Enquire
13	238292	COMPL. FRONT VACUUM PIPE	238292 COMPL. FRONT VACUUM PIPE Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
14	258711	CLIP	258711 CLIP Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
14	258711	CLIP	258711 CLIP Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
15	291579	COMPL. KAISER PIPE MOUNTING BRACKET	291579 COMPL. KAISER PIPE MOUNTING BRACKET Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
15	291579	COMPL. KAISER PIPE MOUNTING BRACKET	291579 COMPL. KAISER PIPE MOUNTING BRACKET Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
16	268340	BRACKET	268340 BRACKET Applicable for GOLFO; Applicable from Ass. No. 91119	-	1	Enquire
16	268340	BRACKET	268340 BRACKET From start of production; Not for EU GS, GOLFO	-	1	Enquire
16	258736	BRACKET	258736 BRACKET Applicable for EU GS; Applicable up to Ass. No. 90801	-	1	Enquire
16	258736	BRACKET	258736 BRACKET Applicable for GOLFO; Applicable up to Ass. No. 91118	-	1	Enquire
16	268340	BRACKET	268340 BRACKET Applicable for EU GS; Applicable from Ass. No. 90802	-	1	Enquire
17	140130	CLIP	140130 CLIP	-	2	Enquire
18	13432070	HOSE COLLAR	13432070 HOSE COLLAR D. 15.7	-	2	Enquire
19	262568	COMPL. BRAKE FLUID RESERVOIR	262568 COMPL. BRAKE FLUID RESERVOIR After depletion, order loose components; Applicable until depletion	-	1	Enquire
