STEERING COLUMN of Ferrari Ferrari 456 M GT/GTA

View All

Ferrari 456 M GT/GTA - STEERING COLUMN

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	661207ADDCOLOURCODE	COMPLETE STEERING WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13271914	SCREW -Valid for "60Â°anniversario"-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10615274	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	169471	SPIRAL CONTACT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15896470	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65734700	UPPER COVER FOR STEERING ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101648	Ring nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159411	UNHOOK DEVIATION ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11066876	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134070	SPACER WASHER mm. 1,0	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11060076	Seeger Ring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134065	SPACER WASHER mm. 1,0	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134061	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157968	UPPER SHAFT FOR STEERING CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11001224	Stud bolt	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	175817	COLUMN SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	162547	DOORS LOCKS SET COMPLETE ANTI-THEFT DEVICE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168046	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157386	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150945	COMPLETE THED WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604079	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14302921	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	171835	TOOTHED WHEEL SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14303374	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	152044	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156061	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	100660	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147985	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168055	LOCK LEVER FOR STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101611	BALL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155865	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	163593	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	175715	SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10730921	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157639	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	178004	COLUMN SUPPORT BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11021111	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63895900	LOWER COVER FOR STEERING ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13275217	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	170010	BLANK KEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157385	PILOT SIDE SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13274117	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177973	L.H. SLIDING ELEMENT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902524	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64450700	UNDER COLUMN PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64450900	L.H. FILLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64450800	R.H. FILLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64509000	L.H. OUTER INSERT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64508900	R.H. OUTER INSERT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	169982	ELECTRO-MAGNET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	169984	DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	169983	ELECTRO-MAGNET LINK CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	179121	BRAKE PEDAL RETURN SMALL PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	179120	CLUTCH PEDAL RETURN SMALL PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231625	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64890600	PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	86574700	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	177972	R.H. SLIDING ELEMENT	177972 R.H. SLIDING ELEMENT	-	1	Enquire
-	180324	COLUMN SUPPORT BRACKET	180324 COLUMN SUPPORT BRACKET Valid from car Ass. Nr. 32065	-	1	Enquire
-	64889500	LOWER COVER FOR STEERING ROD	64889500 LOWER COVER FOR STEERING ROD ROD / Valid for 456M GTA	-	1	Enquire
-	178008	COLUMN SUPPORT	178008 COLUMN SUPPORT Valid for 456M GTA	-	1	Enquire
-	164514	DOORS LOCKS SET COMPLETE ANTI-THEFT DEVICE	164514 DOORS LOCKS SET COMPLETE ANTI-THEFT DEVICE DOORS LOCKS SET AND KEY / Valid for 456M GTA /	-	1	Enquire
-	134071	DITTO, THICKNESS mm. 1.1	134071 DITTO, THICKNESS mm. 1.1	-	1	Enquire
-	134072	DITTO, THICKNESS mm. 1.2	134072 DITTO, THICKNESS mm. 1.2	-	1	Enquire
-	134073	DITTO, THICKNESS mm. 1.3	134073 DITTO, THICKNESS mm. 1.3	-	1	Enquire
-	134074	DITTO, THICKNESS mm. 1.4	134074 DITTO, THICKNESS mm. 1.4	-	1	Enquire
-	134066	DITTO, THICKNESS mm. 1.1	134066 DITTO, THICKNESS mm. 1.1	-	1	Enquire
-	134067	DITTO, THICKNESS mm. 1.2	134067 DITTO, THICKNESS mm. 1.2	-	1	Enquire
-	134068	DITTO, THICKNESS mm. 1.3	134068 DITTO, THICKNESS mm. 1.3	-	1	Enquire
-	134069	DITTO, THICKNESS mm. 1.4	134069 DITTO, THICKNESS mm. 1.4	-	1	Enquire
-	661207	COMPLETE STEERING WHEEL	661207 COMPLETE STEERING WHEEL	-	1	Enquire
1	661207ADDCOLOURCODE	COMPLETE STEERING WHEEL	661207ADDCOLOURCODE COMPLETE STEERING WHEEL Not as spare part now / Replaced by 661207..	-	1	Enquire
2	13271914	SCREW -Valid for "60Â°anniversario"-	13271914 SCREW -Valid for "60Â°anniversario"-	-	3	Enquire
3	10615274	WASHER	10615274 WASHER	-	3	Enquire
4	169471	SPIRAL CONTACT	169471 SPIRAL CONTACT	-	1	Enquire
5	15896470	NUT	15896470 NUT	-	2	Enquire
6	12604178	Washer	12604178 Washer	-	2	Enquire
7	65734700	UPPER COVER FOR STEERING ROD	65734700 UPPER COVER FOR STEERING ROD ROD	-	1	Enquire
8	101648	Ring nut	101648 Ring nut	-	1	Enquire
9	159411	UNHOOK DEVIATION ASSEMBLY	159411 UNHOOK DEVIATION ASSEMBLY	-	1	Enquire
10	11066876	SEEGER RING	11066876 SEEGER RING	-	1	Enquire
11	134070	SPACER WASHER mm. 1,0	134070 SPACER WASHER mm. 1,0 THINCKNESS mm.1.0	-	1	Enquire
12	11060076	Seeger Ring	11060076 Seeger Ring	-	2	Enquire
13	134065	SPACER WASHER mm. 1,0	134065 SPACER WASHER mm. 1,0 THINCKNESS mm.1.0	-	1	Enquire
14	134061	BEARING	134061 BEARING	-	2	Enquire
15	157968	UPPER SHAFT FOR STEERING CONTROL	157968 UPPER SHAFT FOR STEERING CONTROL CONTROL	-	1	Enquire
16	11001224	Stud bolt	11001224 Stud bolt	-	2	Enquire
17	175817	COLUMN SUPPORT	175817 COLUMN SUPPORT Not for 456M GTA	-	1	Enquire
18	162547	DOORS LOCKS SET COMPLETE ANTI-THEFT DEVICE	162547 DOORS LOCKS SET COMPLETE ANTI-THEFT DEVICE DOORS LOCKS SET AND KEY / Not for 456M GTA /	-	1	Enquire
19	168046	SCREW	168046 SCREW	-	1	Enquire
20	157386	CLIP	157386 CLIP	-	4	Enquire
21	12604178	Washer	12604178 Washer	-	6	Enquire
22	150945	COMPLETE THED WHEEL	150945 COMPLETE THED WHEEL	-	1	Enquire
23	12604079	WASHER	12604079 WASHER	-	1	Enquire
24	62769800	WASHER	62769800 WASHER	-	1	Enquire
25	14302921	SCREW	14302921 SCREW	-	1	Enquire
26	171835	TOOTHED WHEEL SENSOR	171835 TOOTHED WHEEL SENSOR	-	1	Enquire
27	14303374	SCREW	14303374 SCREW	-	2	Enquire
28	152044	PIN	152044 PIN	-	2	Enquire
29	156061	BUSHING	156061 BUSHING	-	4	Enquire
30	100660	WASHER	100660 WASHER	-	2	Enquire
31	147985	NUT	147985 NUT	-	2	Enquire
32	168055	LOCK LEVER FOR STEERING COLUMN	168055 LOCK LEVER FOR STEERING COLUMN COLUMN	-	1	Enquire
33	101611	BALL	101611 BALL	-	1	Enquire
34	155865	SPRING	155865 SPRING	-	1	Enquire
35	163593	SPACER	163593 SPACER	-	2	Enquire
36	175715	SHAFT	175715 SHAFT	-	1	Enquire
37	10730921	WASHER	10730921 WASHER	-	1	Enquire
38	148020	NUT	148020 NUT	-	1	Enquire
39	157639	SPRING	157639 SPRING	-	1	Enquire
40	178004	COLUMN SUPPORT BRACKET	178004 COLUMN SUPPORT BRACKET Valid till car Ass. Nr. 32064	-	1	Enquire
41	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	6	Enquire
42	12643724	WASHER	12643724 WASHER	-	6	Enquire
43	11021111	SCREW	11021111 SCREW	-	2	Enquire
44	63895900	LOWER COVER FOR STEERING ROD	63895900 LOWER COVER FOR STEERING ROD ROD / Not for 456M GTA	-	1	Enquire
45	13275217	SCREW	13275217 SCREW	-	2	Enquire
46	170010	BLANK KEY	170010 BLANK KEY	-	-	Enquire
47	157385	PILOT SIDE SPRING	157385 PILOT SIDE SPRING	-	4	Enquire
48	13274117	SCREW	13274117 SCREW	-	4	Enquire
49	177973	L.H. SLIDING ELEMENT	177973 L.H. SLIDING ELEMENT	-	1	Enquire
50	10902524	SCREW	10902524 SCREW	-	4	Enquire
51	10519424	WASHER	10519424 WASHER	-	6	Enquire
52	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	6	Enquire
53	64450700	UNDER COLUMN PLATE	64450700 UNDER COLUMN PLATE	-	1	Enquire
54	64450900	L.H. FILLER	64450900 L.H. FILLER	-	1	Enquire
55	64450800	R.H. FILLER	64450800 R.H. FILLER	-	1	Enquire
56	64509000	L.H. OUTER INSERT	64509000 L.H. OUTER INSERT	-	1	Enquire
57	64508900	R.H. OUTER INSERT	64508900 R.H. OUTER INSERT	-	1	Enquire
58	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	5	Enquire
59	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	5	Enquire
60	169982	ELECTRO-MAGNET	169982 ELECTRO-MAGNET Valid for 456M GTA	-	1	Enquire
61	169984	DOWEL	169984 DOWEL Valid for 456M GTA	-	2	Enquire
62	169983	ELECTRO-MAGNET LINK CABLE	169983 ELECTRO-MAGNET LINK CABLE CABLE / Valid for 456M GTA	-	1	Enquire
63	179121	BRAKE PEDAL RETURN SMALL PLATE	179121 BRAKE PEDAL RETURN SMALL PLATE	-	1	Enquire
64	179120	CLUTCH PEDAL RETURN SMALL PLATE	179120 CLUTCH PEDAL RETURN SMALL PLATE	-	1	Enquire
65	231625	SCREW	231625 SCREW	-	2	Enquire
66	64890600	PLUG	64890600 PLUG Valid for 456M GTA	-	1	Enquire
67	86574700	SCREW	86574700 SCREW Valid from car Ass. Nr. 32065	-	2	Enquire
