DRIVING SHAFT - CONNECTING RODS AND PISTONS of Ferrari Ferrari 456 GT/GTA

View All

Ferrari 456 GT/GTA - DRIVING SHAFT - CONNECTING RODS AND PISTONS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	140501	CRANKSHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	163528	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4150813	Shim for rear support	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	103877	GROOVED BALL BEARING D.30-35	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	144876	TAB	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155613	COMPLETE CONNECTING ROD AND HAT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150966	CONNECTING ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	170047	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	106183	CONNECTING ROD HALF BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156166	PISTON WITH RINGS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154717	GUDGEON PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	166901	STOP RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	193051	Flywheel	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201755	Bolt Hex Head M10 x 1.25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215963	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168565	Torsion Damper	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140925	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140922	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159987	PISTONS RINGS SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	111540	PLUG	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	173535	PISTONS RINGS SET	173535 PISTONS RINGS SET Valid from engine Nr. 39700, for / USA from engine Nr. 38754, for / CH from engine Nr. 38734	-	12	Enquire
-	168565	Torsion Damper	168565 Torsion Damper Not for 456 GTA / Valid after stock exhaustion of 155410	-	1	Enquire
-	175690	TORSION DAMPER	175690 TORSION DAMPER Valid for 456 GTA	-	1	Enquire
-	155750	Screw: (mm 1,25 thread) -For	155750 Screw: (mm 1,25 thread) -For Valid for 456 GTA	-	8	Enquire
-	193051	Flywheel	193051 Flywheel Not for 456 GTA / Replace the 151258	-	1	Enquire
-	170774	ENGINE FLYWHEEL	170774 ENGINE FLYWHEEL Valid for 456 GTA	-	1	Enquire
-	168173	PISTON WITH RINGS	168173 PISTON WITH RINGS Valid for MOTRONIC 5.2	-	12	Enquire
-	163812ROR163812G	PISTON WITH RINGS	163812ROR163812G PISTON WITH RINGS Valid for MOTRONIC 2.7 / Valid from engine Nr. 39700 / For USA from engine Nr. 38754 / ing5r	-	12	Enquire
-	106184	1st undersize 0,254 mm. on Ã˜	106184 1st undersize 0,254 mm. on Ã˜ 1st UNDERSIZE mm 0.254	-	-	Enquire
-	106185	2nd undersize 0,508 mm on Ã˜	106185 2nd undersize 0,508 mm on Ã˜ 2nd UNDERSIZE mm 0.508	-	-	Enquire
-	164109	LOWER SHIM RING	164109 LOWER SHIM RING 1st OVERSIZE mm 0.127 / Valid for MOTRONIC 5.2 / With the complete series 173485	-	-	Enquire
-	164110	LOWER SHIM RING	164110 LOWER SHIM RING 2nd OVERSIZE mm 0,254 / Valid for MOTRONIC 5.2 / With the complete series 173486	-	-	Enquire
-	164113	UPPER SHIM RING	164113 UPPER SHIM RING 2nd OVERSIZE mm 0,254 / Valid for MOTRONIC 5.2 / With the complete series 173486	-	-	Enquire
-	164108	LOWER SHIM RING	164108 LOWER SHIM RING Valid for MOTRONIC 5.2 / With the complete series 173484	-	2	Enquire
-	164111	UPPER SHIM RING	164111 UPPER SHIM RING Valid for MOTRONIC 5.2 / With the complete series 173484	-	2	Enquire
-	164112	UPPER SHIM RING	164112 UPPER SHIM RING 1st OVERSIZE mm 0.127 / Valid for MOTRONIC 5.2 / With the complete series 173485	-	-	Enquire
-	113984	SHIM 1st OVERSIZE mm 0.127	113984 SHIM 1st OVERSIZE mm 0.127 Valid for MOTRONIC 2.7 / With the complete series 153214 /	-	-	Enquire
-	100147	SHIM 2nd OVERSIZE mm 0.250	100147 SHIM 2nd OVERSIZE mm 0.250 Valid for MOTRONIC 2.7 / With the complete series 153215 /	-	-	Enquire
-	153215	HALF BEARING SET - 2nd UNDERSIZE mm. 0,508	153215 HALF BEARING SET - 2nd UNDERSIZE mm. 0,508 2nd UNDERSIZE mm. 0,508 / Valid for MOTRONIC 2.7	-	1	Enquire
-	173486	COMPLETE HALF-BEARING SET	173486 COMPLETE HALF-BEARING SET 2nd UNDERSIZE mm. 0,508 / Valid for MOTRONIC 5.2	-	1	Enquire
-	173484	HALF-BEARINGS COMPLETE SERIES	173484 HALF-BEARINGS COMPLETE SERIES Valid for MOTRONIC 5.2 /	-	1	Enquire
-	153214	HALF BEARING SET - 1st UNDERSIZE mm. 0,254	153214 HALF BEARING SET - 1st UNDERSIZE mm. 0,254 1st UNDERSIZE mm. 0,254 / Valid for MOTRONIC 2.7	-	1	Enquire
-	173485	COMPLETE HALF-BEARING SET	173485 COMPLETE HALF-BEARING SET 1st UNDERSIZE mm. 0,254 / Valid for MOTRONIC 5.2	-	1	Enquire
-	153213	HALF BEARING SET -NOMINAL-	153213 HALF BEARING SET -NOMINAL- Valid for MOTRONIC 2.7 /	-	1	Enquire
1	140501	CRANKSHAFT	140501 CRANKSHAFT	-	1	Enquire
2	163528	THREADED PLUG	163528 THREADED PLUG	-	1	Enquire
8	4150813	Shim for rear support	4150813 Shim for rear support Valid for MOTRONIC 2.7 / With the complete series 153213	-	2	Enquire
9	103877	GROOVED BALL BEARING D.30-35	103877 GROOVED BALL BEARING D.30-35 Not for 456 GTA	-	1	Enquire
10	144876	TAB	144876 TAB	-	1	Enquire
11	155613	COMPLETE CONNECTING ROD AND HAT	155613 COMPLETE CONNECTING ROD AND HAT AND HAT	-	12	Enquire
12	150966	CONNECTING ROD	150966 CONNECTING ROD	-	24	Enquire
13	170047	BUSHING	170047 BUSHING	-	12	Enquire
14	106183	CONNECTING ROD HALF BEARING	106183 CONNECTING ROD HALF BEARING	-	24	Enquire
15	156166	PISTON WITH RINGS	156166 PISTON WITH RINGS Valid for MOTRONIC 2.7 / Valid till engine Nr. 39699 / For USA till engine Nr. 38753 / For CH till engine Nr. 38733	-	12	Enquire
19	154717	GUDGEON PIN	154717 GUDGEON PIN	-	12	Enquire
20	166901	STOP RING	166901 STOP RING	-	24	Enquire
21	193051	Flywheel	193051 Flywheel Not for 456 GTA / Not as spare part replaced by 173760	-	1	Enquire
22	201755	Bolt Hex Head M10 x 1.25	201755 Bolt Hex Head M10 x 1.25 Not for 456 GTA	-	8	Enquire
23	215963	WASHER	215963 WASHER Not for 456 GTA	-	1	Enquire
24	168565	Torsion Damper	168565 Torsion Damper Not for 456 GTA / Valid till stock exhaustion	-	1	Enquire
25	140925	SCREW	140925 SCREW	-	1	Enquire
26	140922	WASHER	140922 WASHER	-	1	Enquire
27	159987	PISTONS RINGS SET	159987 PISTONS RINGS SET Valid till engine Nr. 39699, for / USA till engine Nr. 38753, for / CH till engine Nr. 38733	-	12	Enquire
28	111540	PLUG	111540 PLUG Valid for 456 GTA	-	6	Enquire
