PEDAL BOARD -Applicable for GD- of Ferrari Ferrari 430 Scuderia

View All

Ferrari 430 Scuderia - PEDAL BOARD -Applicable for GD-

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	214215	PEDAL BOARD MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177120	PEDAL MOUNTING PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201578	COMPLETE BRAKE PEDAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	103163	SELF-LUBRICATING BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	176475	BALL-JOINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	199754	FORK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66535800	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147985	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	176522	PLASTIC WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16102314	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902424	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	219557	SWITCH MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	958694	PUSH-BUTTON SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	178496	SHIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	113836	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	113835	WASHER	Enquire	To Order
	113836	WASHER	Enquire	To Order
	106083	WASHER	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	13516924	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104030	NYLOC NUT M8 X 1.25 X 9.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13517524	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601374	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177131	PEDAL BOARD MOUNTING GASKET	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	214215	PEDAL BOARD MOUNTING	214215 PEDAL BOARD MOUNTING Applicable for GD	-	1	Enquire
2	177120	PEDAL MOUNTING PIN	177120 PEDAL MOUNTING PIN Applicable for GD	-	1	Enquire
3	201578	COMPLETE BRAKE PEDAL	201578 COMPLETE BRAKE PEDAL Applicable for GD	-	1	Enquire
4	103163	SELF-LUBRICATING BUSHING	103163 SELF-LUBRICATING BUSHING Applicable for GD	-	2	Enquire
5	176475	BALL-JOINT	176475 BALL-JOINT Applicable for GD	-	1	Enquire
6	199754	FORK	199754 FORK Applicable for GD	-	2	Enquire
7	66535800	SCREW	66535800 SCREW Applicable for GD	-	1	Enquire
8	147985	NUT	147985 NUT Applicable for GD	-	1	Enquire
9	176522	PLASTIC WASHER	176522 PLASTIC WASHER Applicable for GD	-	2	Enquire
10	16102314	NUT	16102314 NUT Applicable for GD	-	1	Enquire
11	10902424	SCREW	10902424 SCREW Applicable for GD	-	1	Enquire
12	10519424	WASHER	10519424 WASHER Applicable for GD	-	1	Enquire
13	127494	WASHER	127494 WASHER Applicable for GD	-	1	Enquire
14	219557	SWITCH MOUNTING	219557 SWITCH MOUNTING Applicable for GD	-	1	Enquire
15	958694	PUSH-BUTTON SWITCH	958694 PUSH-BUTTON SWITCH Applicable for GD	-	1	Enquire
16	178496	SHIM	178496 SHIM Applicable for GD	-	1	Enquire
17	113836	WASHER	113836 WASHER Th. 1.4 mm; Applicable for GD	-	2	Enquire
18	113835	WASHER	113835 WASHER Th. 1.3 mm; Installed if necessary; Applicable for GD	-	1	Enquire
18	113836	WASHER	113836 WASHER Th. 1.4 mm; Installed if necessary; Applicable for GD	-	1	Enquire
18	106083	WASHER	106083 WASHER Th. 1 mm; Applicable for GD	-	1	Enquire
18	113833	WASHER	113833 WASHER Th. 1.1 mm; Installed if necessary; Applicable for GD	-	1	Enquire
18	113834	WASHER	113834 WASHER Th. 1.2 mm; Installed if necessary; Applicable for GD	-	1	Enquire
19	13516924	STUD BOLT	13516924 STUD BOLT Applicable for GD	-	9	Enquire
20	12638524	WASHER	12638524 WASHER Applicable for GD	-	9	Enquire
21	104030	NYLOC NUT M8 X 1.25 X 9.5	104030 NYLOC NUT M8 X 1.25 X 9.5 Applicable for GD	-	9	Enquire
22	13517524	STUD BOLT	13517524 STUD BOLT Applicable for GD	-	2	Enquire
23	12601374	WASHER	12601374 WASHER Applicable for GD	-	2	Enquire
24	177131	PEDAL BOARD MOUNTING GASKET	177131 PEDAL BOARD MOUNTING GASKET Applicable for GD	-	1	Enquire
