CAPOTE MOVEMENT - UPPER PART of Ferrari Ferrari 360 Spider

View All

Ferrari 360 Spider - CAPOTE MOVEMENT - UPPER PART

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	66458300	RH SWING ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66693900	RH SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66693000	RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66688100	PULLEY BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66688000	PULLEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66687900	PULLEY BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66687800	PULLEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66375700	STRETCH CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66688200	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682200	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682100	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682800	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682700	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66683200	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66683300	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682900	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66694100	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66683100	RH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66683000	LH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682400	SEEGER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682000	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682300	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66460300	RH PILLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682500	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66682600	SEEGER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66681800	RH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66458100	R.H. LONGITUDINAL TIE ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67048800	TRIPLE JOINT COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67048900	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67048500	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67048600	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67048700	SHEATH	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	67047100	COMPLETE CABLE LH TRIPLE JOINT	67047100 COMPLETE CABLE LH TRIPLE JOINT Valid from car Ass. Nr. 42510	-	1	Enquire
-	67047200	RH TRIPLE JOINT COMPLETE WITH CABLE	67047200 RH TRIPLE JOINT COMPLETE WITH CABLE Valid from car Ass. Nr. 42510	-	1	Enquire
-	66458000	L.H. LONGITUDINAL TIE ROD	66458000 L.H. LONGITUDINAL TIE ROD Not as spare part / Till car Ass. Nr.42509 replace with the / new triple joint R.h. and L.h. / 67047100 + 67047200 together	-	1	Enquire
-	66681900	LH BRACKET	66681900 LH BRACKET	-	1	Enquire
-	66460200	LH PILLAR	66460200 LH PILLAR	-	1	Enquire
-	67047300	TENSIONING CABLE	67047300 TENSIONING CABLE Valid from Ass. Nr. 42510	-	2	Enquire
-	66458200	LH SWING ARM	66458200 LH SWING ARM	-	1	Enquire
-	66694000	LH SHIELD	66694000 LH SHIELD	-	1	Enquire
1	66458300	RH SWING ARM	66458300 RH SWING ARM	-	1	Enquire
2	66693900	RH SHIELD	66693900 RH SHIELD	-	1	Enquire
3	66693000	RIVET	66693000 RIVET	-	4	Enquire
4	66688100	PULLEY BRACKET	66688100 PULLEY BRACKET 37 mm	-	2	Enquire
5	66688000	PULLEY	66688000 PULLEY 37 mm	-	2	Enquire
6	66687900	PULLEY BRACKET	66687900 PULLEY BRACKET 20 mm	-	6	Enquire
7	66687800	PULLEY	66687800 PULLEY 20 mm	-	6	Enquire
8	66375700	STRETCH CABLE	66375700 STRETCH CABLE Valid till Ass. Nr. 42509	-	2	Enquire
9	66688200	SPRING	66688200 SPRING	-	2	Enquire
10	66682200	CLIP	66682200 CLIP	-	12	Enquire
11	66682100	PIN	66682100 PIN	-	2	Enquire
12	66682800	PIN	66682800 PIN	-	2	Enquire
13	66682700	PIN	66682700 PIN	-	2	Enquire
14	66683200	PIN	66683200 PIN	-	2	Enquire
15	66683300	PIN	66683300 PIN	-	2	Enquire
16	66682900	PIN	66682900 PIN	-	2	Enquire
17	66694100	WASHER	66694100 WASHER	-	2	Enquire
18	66683100	RH BRACKET	66683100 RH BRACKET	-	2	Enquire
19	66683000	LH BRACKET	66683000 LH BRACKET	-	2	Enquire
20	66682400	SEEGER	66682400 SEEGER	-	4	Enquire
21	66682000	PIN	66682000 PIN	-	2	Enquire
22	66682300	PIN	66682300 PIN	-	2	Enquire
23	66460300	RH PILLAR	66460300 RH PILLAR	-	1	Enquire
24	66682500	PIN	66682500 PIN	-	2	Enquire
25	66682600	SEEGER	66682600 SEEGER	-	2	Enquire
26	66681800	RH BRACKET	66681800 RH BRACKET	-	1	Enquire
27	66458100	R.H. LONGITUDINAL TIE ROD	66458100 R.H. LONGITUDINAL TIE ROD Not as spare part / Till car Ass. Nr. 42509 replace with the / new triple joint R.h. and L.h. / 67047100 + 67047200 together	-	1	Enquire
28	67048800	TRIPLE JOINT COLUMN	67048800 TRIPLE JOINT COLUMN	-	2	Enquire
29	67048900	SCREW	67048900 SCREW	-	4	Enquire
30	67048500	SCREW	67048500 SCREW	-	2	Enquire
31	67048600	NUT	67048600 NUT	-	2	Enquire
32	67048700	SHEATH	67048700 SHEATH	-	2	Enquire
