Steering Column of Ferrari Ferrari 348 TB (1993)

View All

Ferrari 348 TB (1993) - Steering Column

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	140945	COMPLETE STEERING WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101648	Ring nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601774	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	138048	Steering wheel coating	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137819	ELECTRIC HORN PUSH BUTTON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154563	UNHOOK DEVIATION	Enquire	To Order
	154563	UNHOOK DEVIATION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15896470	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11060076	Seeger Ring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134069	DITTO, THICKNESS mm. 1.4	Enquire	To Order
	134066	DITTO, THICKNESS mm. 1.1	Enquire	To Order
	134068	DITTO, THICKNESS mm. 1.3	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	134061	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11001524	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	133903	COLUMN SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13525170	THREADED INSERT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	138052	ANTI THEFT DEVICE (COMPLETE OF DOORS LOCKS SET)	Enquire	To Order
	138052	ANTI THEFT DEVICE (COMPLETE OF DOORS LOCKS SET)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101106	Tongue	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140939	UPPER SHAFT FOR STEERING CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134070	SPACER WASHER mm. 1,0	Enquire	To Order
	134071	DITTO, THICKNESS mm. 1.1	Enquire	To Order
	134072	DITTO, THICKNESS mm. 1.2	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	11066876	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	133870	SHAFT FOR LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14163870	FLEXIBLE PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	114865	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125185	LOCK LEVER FOR STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134504	THREADED BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127496	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16043324	SCREW M8 X 18	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	138712	LOWER SHAFT FOR STEERING CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125518	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	95401152	BLANK KEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63318700	COVER FOR STEERING ROD	Enquire	To Order
	63318700	COVER FOR STEERING ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15961107	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13274114	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15960507	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150427	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150427	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121611	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	140945	COMPLETE STEERING WHEEL	140945 COMPLETE STEERING WHEEL	-	1	Enquire
2	101648	Ring nut	101648 Ring nut	-	1	Enquire
3	12601774	WASHER	12601774 WASHER	-	1	Enquire
4	138048	Steering wheel coating	138048 Steering wheel coating	-	1	Enquire
5	137819	ELECTRIC HORN PUSH BUTTON	137819 ELECTRIC HORN PUSH BUTTON	-	1	Enquire
6	154563	UNHOOK DEVIATION	154563 UNHOOK DEVIATION Valid from car Ass. Nr. 9227 and	-	1	Enquire
6	154563	UNHOOK DEVIATION	154563 UNHOOK DEVIATION Valid till car Ass. Nr. 9226 Not for car Ass. Nr. 8944, 8945,8946	-	1	Enquire
7	15896470	NUT	15896470 NUT (minimum order quantity = 20)	-	2	Enquire
8	12604178	Washer	12604178 Washer	-	2	Enquire
9	11060076	Seeger Ring	11060076 Seeger Ring	-	2	Enquire
10	134069	DITTO, THICKNESS mm. 1.4	134069 DITTO, THICKNESS mm. 1.4 mm. 1,4	-	1	Enquire
10	134066	DITTO, THICKNESS mm. 1.1	134066 DITTO, THICKNESS mm. 1.1 mm. 1,1	-	1	Enquire
10	134068	DITTO, THICKNESS mm. 1.3	134068 DITTO, THICKNESS mm. 1.3 mm. 1,3	-	1	Enquire
10	134067	DITTO, THICKNESS mm. 1.2	134067 DITTO, THICKNESS mm. 1.2 mm. 1,2	-	1	Enquire
10	134065	SPACER WASHER mm. 1,0	134065 SPACER WASHER mm. 1,0 mm. 1,0	-	1	Enquire
11	134061	BEARING	134061 BEARING	-	2	Enquire
12	11001524	STUD	11001524 STUD	-	2	Enquire
13	133903	COLUMN SUPPORT	133903 COLUMN SUPPORT	-	1	Enquire
14	13525170	THREADED INSERT	13525170 THREADED INSERT	-	2	Enquire
15	138052	ANTI THEFT DEVICE (COMPLETE OF DOORS LOCKS SET)	138052 ANTI THEFT DEVICE (COMPLETE OF DOORS LOCKS SET) Not for USA, CDN, J	-	1	Enquire
15	138052	ANTI THEFT DEVICE (COMPLETE OF DOORS LOCKS SET)	138052 ANTI THEFT DEVICE (COMPLETE OF DOORS LOCKS SET) Valid for USA, CDN, J	-	1	Enquire
16	101106	Tongue	101106 Tongue	-	1	Enquire
17	140939	UPPER SHAFT FOR STEERING CONTROL	140939 UPPER SHAFT FOR STEERING CONTROL	-	1	Enquire
18	134070	SPACER WASHER mm. 1,0	134070 SPACER WASHER mm. 1,0 mm. 1,0	-	1	Enquire
18	134071	DITTO, THICKNESS mm. 1.1	134071 DITTO, THICKNESS mm. 1.1 mm. 1,1	-	1	Enquire
18	134072	DITTO, THICKNESS mm. 1.2	134072 DITTO, THICKNESS mm. 1.2 mm. 1,2	-	1	Enquire
18	134073	DITTO, THICKNESS mm. 1.3	134073 DITTO, THICKNESS mm. 1.3 mm. 1,3	-	1	Enquire
18	134074	DITTO, THICKNESS mm. 1.4	134074 DITTO, THICKNESS mm. 1.4 mm. 1,4	-	1	Enquire
19	11066876	SEEGER RING	11066876 SEEGER RING	-	1	Enquire
20	133870	SHAFT FOR LEVER	133870 SHAFT FOR LEVER	-	1	Enquire
21	14163870	FLEXIBLE PIN	14163870 FLEXIBLE PIN	-	1	Enquire
22	114865	WASHER	114865 WASHER	-	2	Enquire
23	148020	NUT	148020 NUT	-	1	Enquire
24	125185	LOCK LEVER FOR STEERING COLUMN	125185 LOCK LEVER FOR STEERING COLUMN	-	1	Enquire
25	134504	THREADED BUSHING	134504 THREADED BUSHING	-	2	Enquire
26	127496	WASHER	127496 WASHER	-	2	Enquire
27	16043324	SCREW M8 X 18	16043324 SCREW M8 X 18	-	2	Enquire
28	12638524	WASHER	12638524 WASHER	-	4	Enquire
29	138712	LOWER SHAFT FOR STEERING CONTROL	138712 LOWER SHAFT FOR STEERING CONTROL	-	1	Enquire
30	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
31	125518	SCREW	125518 SCREW	-	1	Enquire
32	95401152	BLANK KEY	95401152 BLANK KEY	-	1	Enquire
33	63318700	COVER FOR STEERING ROD	63318700 COVER FOR STEERING ROD Valid till car Ass. Nr. 9226 Not for car Ass. Nr. 8944, 8945,8946	-	1	Enquire
33	63318700	COVER FOR STEERING ROD	63318700 COVER FOR STEERING ROD Valid from car Ass. Nr. 9227 and for car Ass. Nr. 8944, 8945, 8946	-	1	Enquire
34	15961107	SCREW	15961107 SCREW	-	2	Enquire
35	12643724	WASHER	12643724 WASHER	-	4	Enquire
36	13274114	SCREW	13274114 SCREW	-	2	Enquire
37	12604178	Washer	12604178 Washer	-	2	Enquire
38	15960507	SCREW	15960507 SCREW	-	2	Enquire
39	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	2	Enquire
40	150427	SCREW	150427 SCREW	-	1	Enquire
41	150427	SCREW	150427 SCREW	-	1	Enquire
42	121611	SCREW	121611 SCREW	-	2	Enquire
