FUEL TANK of Ferrari Ferrari 296 GTS Europe

View All

Ferrari 296 GTS Europe - FUEL TANK

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	780722	RH FUEL TANK WITH CAPS AND PAINT AND VIBRATION DAMPERS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	940193	LH FUEL TANK	Enquire	To Order
	948368	LH FUEL TANK WITH CAPS AND PAINT AND VIBRATION DAMPERS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	983355	RH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	983175	LH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	987200	TUBO COLLEGAMENTO SERBATOI	Enquire	To Order
	988896	COMPL. FUEL TANK CONNECTOR PIPE	Enquire	To Order
	960934	COMPL. FUEL TANK CONNECTOR PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262116	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	840354	TANK PIPE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16281827	SCREW M5 X 14	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262114	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	838726	COMPL. RH FUEL PUMP KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	838682	COMPL. LH FUEL PUMP KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	899649	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	753437	FLANGE FASTENER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11001124	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254078	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	259508	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	864964	COMPL. CORNER ADAPTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	801035	RH FUEL TANK INTERNAL VALVE KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	784217	LH FUEL TANK INTERNAL VALVE KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	856964	PIPING VALVE MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	954080	HOOK-UP WIRE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	237407	ANTI SPIT-BACK VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	744683	COMPL. FUEL FILLER NECK	Enquire	To Order
	894321	COMPL. FUEL FILLER NECK	Enquire	To Order
	894321	COMPL. FUEL FILLER NECK	Enquire	To Order

...and 4 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	11449470	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	MC43254	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10815787	CLAMP	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	780722	RH FUEL TANK WITH CAPS AND PAINT AND VIBRATION DAMPERS	780722 RH FUEL TANK WITH CAPS AND PAINT AND VIBRATION DAMPERS	-	1	Enquire
0002	940193	LH FUEL TANK	940193 LH FUEL TANK No longer supplied - Replaced by 948368	-	1	Enquire
0002	948368	LH FUEL TANK WITH CAPS AND PAINT AND VIBRATION DAMPERS	948368 LH FUEL TANK WITH CAPS AND PAINT AND VIBRATION DAMPERS	-	1	Enquire
0003	983355	RH HOSE	983355 RH HOSE	-	1	Enquire
0004	983175	LH HOSE	983175 LH HOSE	-	1	Enquire
0005	987200	TUBO COLLEGAMENTO SERBATOI	987200 TUBO COLLEGAMENTO SERBATOI	-	1	Enquire
0005	988896	COMPL. FUEL TANK CONNECTOR PIPE	988896 COMPL. FUEL TANK CONNECTOR PIPE Applies until depletion	-	1	Enquire
0005	960934	COMPL. FUEL TANK CONNECTOR PIPE	960934 COMPL. FUEL TANK CONNECTOR PIPE Applicable after depletion of 988896	-	1	Enquire
0006	262116	COLLAR	262116 COLLAR	-	2	Enquire
0007	840354	TANK PIPE MOUNTING BRACKET	840354 TANK PIPE MOUNTING BRACKET	-	1	Enquire
0008	16281827	SCREW M5 X 14	16281827 SCREW M5 X 14 M5 X 14	-	5	Enquire
0009	262114	COLLAR	262114 COLLAR	-	2	Enquire
0010	838726	COMPL. RH FUEL PUMP KIT	838726 COMPL. RH FUEL PUMP KIT	-	1	Enquire
0011	838682	COMPL. LH FUEL PUMP KIT	838682 COMPL. LH FUEL PUMP KIT	-	1	Enquire
0012	899649	O-RING	899649 O-RING	-	2	Enquire
0013	753437	FLANGE FASTENER RING	753437 FLANGE FASTENER RING	-	2	Enquire
0014	11001124	STUD BOLT	11001124 STUD BOLT	-	2	Enquire
0015	85833700	SCREW	85833700 SCREW M5 X 16	-	16	Enquire
0016	254078	CLIP	254078 CLIP	-	4	Enquire
0017	259508	CLIP	259508 CLIP 1 compartment-	-	2	Enquire
0018	864964	COMPL. CORNER ADAPTER	864964 COMPL. CORNER ADAPTER	-	1	Enquire
0019	801035	RH FUEL TANK INTERNAL VALVE KIT	801035 RH FUEL TANK INTERNAL VALVE KIT	-	1	Enquire
0020	784217	LH FUEL TANK INTERNAL VALVE KIT	784217 LH FUEL TANK INTERNAL VALVE KIT	-	1	Enquire
0021	856964	PIPING VALVE MOUNTING	856964 PIPING VALVE MOUNTING	-	3	Enquire
0022	954080	HOOK-UP WIRE	954080 HOOK-UP WIRE	-	1	Enquire
0023	237407	ANTI SPIT-BACK VALVE	237407 ANTI SPIT-BACK VALVE	-	1	Enquire
0024	744683	COMPL. FUEL FILLER NECK	744683 COMPL. FUEL FILLER NECK After depletion, order 894321; Applies until depletion	-	1	Enquire
0024	894321	COMPL. FUEL FILLER NECK	894321 COMPL. FUEL FILLER NECK	-	1	Enquire
0024	894321	COMPL. FUEL FILLER NECK	894321 COMPL. FUEL FILLER NECK	-	1	Enquire
0024	894321	COMPL. FUEL FILLER NECK	894321 COMPL. FUEL FILLER NECK	-	1	Enquire
0024	894321	COMPL. FUEL FILLER NECK	894321 COMPL. FUEL FILLER NECK	-	1	Enquire
0024	894321	COMPL. FUEL FILLER NECK	894321 COMPL. FUEL FILLER NECK	-	1	Enquire
0024	894321	COMPL. FUEL FILLER NECK	894321 COMPL. FUEL FILLER NECK	-	1	Enquire
0025	11449470	COLLAR	11449470 COLLAR	-	1	Enquire
0026	MC43254	CLAMP	MC43254 CLAMP	-	1	Enquire
0027	10815787	CLAMP	10815787 CLAMP	-	2	Enquire
