Find Your Part

Rear Brakes – Callipers and Discs of Ferrari Ferrari 12Cilindri

View All

Ferrari 12Cilindri - Rear Brakes – Callipers and Discs

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	829930	RH REAR CALIPER WITH PADS	Enquire	To Order
	863173	RH REAR CALIPER WITH PADS	Enquire	To Order
	829931	RH REAR CALIPER WITH PADS	Enquire	To Order

...and 33 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	196837	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338397	COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE	Enquire	To Order
	338396	COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	977797	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	116374	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	779769	DISCO FRENO 360X32 CCM-IGC-IR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228131	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228132	SPRING WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	764097	RH EPB CALLIPER	Enquire	To Order
	764096	LH CALLIPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338792	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338392	RH REAR DISC SHIELD	Enquire	To Order
	338391	LH REAR DISC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	250657	SCREW M6 X 14	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004286	REAR PAD SET WITH SPRING	Enquire	To Order
	851788	REAR PAD SET WITH SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70006840	SET OF EPB PADS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11M1930CP	Wiring Harness - Body - Low-Line - Coupe - LHD - MY2013	Enquire	To Order
	11M3339CP	Wiring Harness - Body - Low-Line - Coupe - LHD - MY2015	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11M1292CP	Wiring Harness - Body - Mid-Line - Coupe - LHD	Enquire	To Order
	11M1931CP	Wiring Harness - Body - Mid-Line - Coupe - LHD - MY2013	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004901	REAR DUST GAITER KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215665	BLEED SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215666	PROTECTIVE CAP	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	829930	RH REAR CALIPER WITH PADS	829930 RH REAR CALIPER WITH PADS Anodised black; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863173	RH REAR CALIPER WITH PADS	863173 RH REAR CALIPER WITH PADS Anodised black; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829931	RH REAR CALIPER WITH PADS	829931 RH REAR CALIPER WITH PADS Gloss Black; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863177	RH REAR CALIPER WITH PADS	863177 RH REAR CALIPER WITH PADS Gloss Black; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829922	RH REAR CALIPER WITH PADS	829922 RH REAR CALIPER WITH PADS Corsa red; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863181	RH REAR CALIPER WITH PADS	863181 RH REAR CALIPER WITH PADS Corsa red; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829925	RH REAR CALIPER WITH PADS	829925 RH REAR CALIPER WITH PADS Scuderia red; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863216	RH REAR CALIPER WITH PADS	863216 RH REAR CALIPER WITH PADS Scuderia red; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829927	RH REAR CALIPER WITH PADS	829927 RH REAR CALIPER WITH PADS Gold; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863264	RH REAR CALIPER WITH PADS	863264 RH REAR CALIPER WITH PADS Gold; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829923	RH REAR CALIPER WITH PADS	829923 RH REAR CALIPER WITH PADS Aluminium; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863201	RH REAR CALIPER WITH PADS	863201 RH REAR CALIPER WITH PADS Aluminium; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829928	RH REAR CALIPER WITH PADS	829928 RH REAR CALIPER WITH PADS Blue; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863281	RH REAR CALIPER WITH PADS	863281 RH REAR CALIPER WITH PADS Blue; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829926	RH REAR CALIPER WITH PADS	829926 RH REAR CALIPER WITH PADS Grigio Silverstone; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863227	RH REAR CALIPER WITH PADS	863227 RH REAR CALIPER WITH PADS Grigio Silverstone; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829924	RH REAR CALIPER WITH PADS	829924 RH REAR CALIPER WITH PADS Yellow; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863212	RH REAR CALIPER WITH PADS	863212 RH REAR CALIPER WITH PADS Yellow; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829677	LH REAR CALIPER WITH PADS	829677 LH REAR CALIPER WITH PADS Anodised black; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863172	LH REAR CALIPER WITH PADS	863172 LH REAR CALIPER WITH PADS Anodised black; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829878	LH REAR CALIPER WITH PADS	829878 LH REAR CALIPER WITH PADS Gloss Black; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863175	LH REAR CALIPER WITH PADS	863175 LH REAR CALIPER WITH PADS Gloss Black; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829882	LH REAR CALIPER WITH PADS	829882 LH REAR CALIPER WITH PADS Corsa red; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863179	LH REAR CALIPER WITH PADS	863179 LH REAR CALIPER WITH PADS Corsa red; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829888	LH REAR CALIPER WITH PADS	829888 LH REAR CALIPER WITH PADS Scuderia red; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863214	LH REAR CALIPER WITH PADS	863214 LH REAR CALIPER WITH PADS Scuderia red; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829891	LH REAR CALIPER WITH PADS	829891 LH REAR CALIPER WITH PADS Gold; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863229	LH REAR CALIPER WITH PADS	863229 LH REAR CALIPER WITH PADS Gold; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829885	LH REAR CALIPER WITH PADS	829885 LH REAR CALIPER WITH PADS Aluminium; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863183	LH REAR CALIPER WITH PADS	863183 LH REAR CALIPER WITH PADS Aluminium; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829893	LH REAR CALIPER WITH PADS	829893 LH REAR CALIPER WITH PADS Blue; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863278	LH REAR CALIPER WITH PADS	863278 LH REAR CALIPER WITH PADS Blue; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829889	LH REAR CALIPER WITH PADS	829889 LH REAR CALIPER WITH PADS Grigio Silverstone; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863225	LH REAR CALIPER WITH PADS	863225 LH REAR CALIPER WITH PADS Grigio Silverstone; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
1	829886	LH REAR CALIPER WITH PADS	829886 LH REAR CALIPER WITH PADS Yellow; With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
1	863210	LH REAR CALIPER WITH PADS	863210 LH REAR CALIPER WITH PADS Yellow; With non-bedded-in pads; Applicable for: WA	-	1	Enquire
2	196837	SCREW	196837 SCREW M12 X 1.5 X 105	-	2	Enquire
3	338397	COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE	338397 COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE	-	1	Enquire
3	338396	COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE	338396 COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE	-	1	Enquire
4	977797	HOSE	977797 HOSE Replace as a pair	-	2	Enquire
5	116374	CLIP	116374 CLIP	-	4	Enquire
6	779769	DISCO FRENO 360X32 CCM-IGC-IR	779769 DISCO FRENO 360X32 CCM-IGC-IR	-	2	Enquire
7	228131	SCREW	228131 SCREW M8 X 20	-	4	Enquire
8	228132	SPRING WASHER	228132 SPRING WASHER	-	4	Enquire
9	764097	RH EPB CALLIPER	764097 RH EPB CALLIPER	-	1	Enquire
9	764096	LH CALLIPER	764096 LH CALLIPER	-	1	Enquire
10	338792	SCREW	338792 SCREW M10 X 1.5 X 90	-	4	Enquire
11	338392	RH REAR DISC SHIELD	338392 RH REAR DISC SHIELD	-	1	Enquire
11	338391	LH REAR DISC SHIELD	338391 LH REAR DISC SHIELD	-	1	Enquire
12	250657	SCREW M6 X 14	250657 SCREW M6 X 14 M6 X 14	-	5	Enquire
13	70004286	REAR PAD SET WITH SPRING	70004286 REAR PAD SET WITH SPRING With non-bedded-in pads; Not applicable for: WA	-	1	Enquire
13	851788	REAR PAD SET WITH SPRING	851788 REAR PAD SET WITH SPRING With non-bedded-in pads; Applicable for: WA	-	1	Enquire
14	70006840	SET OF EPB PADS	70006840 SET OF EPB PADS For 2 callipers- -Includes pads, springs, pins and split pins	-	1	Enquire
15	11M1930CP	Wiring Harness - Body - Low-Line - Coupe - LHD - MY2013	11M1930CP Wiring Harness - Body - Low-Line - Coupe - LHD - MY2013 Also contains gear motor screws, O-rings and grease	-	1	Enquire
15	11M3339CP	Wiring Harness - Body - Low-Line - Coupe - LHD - MY2015	11M3339CP Wiring Harness - Body - Low-Line - Coupe - LHD - MY2015 Also contains gear motor screws, O-rings and grease	-	1	Enquire
16	11M1292CP	Wiring Harness - Body - Mid-Line - Coupe - LHD	11M1292CP Wiring Harness - Body - Mid-Line - Coupe - LHD For 1 calliper - Contains gear motor complete with screws, O-rings and grease	-	1	Enquire
16	11M1931CP	Wiring Harness - Body - Mid-Line - Coupe - LHD - MY2013	11M1931CP Wiring Harness - Body - Mid-Line - Coupe - LHD - MY2013 For 1 calliper - Contains gear motor complete with screws, O-rings and grease	-	1	Enquire
17	70004901	REAR DUST GAITER KIT	70004901 REAR DUST GAITER KIT	-	1	Enquire
18	215665	BLEED SCREW	215665 BLEED SCREW	-	4	Enquire
19	215666	PROTECTIVE CAP	215666 PROTECTIVE CAP	-	4	Enquire
