Aston Martin DBS V12 - Body Dash and Cowl (Coupe)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4G43C03014BR	Frame Assembly, Windshield, RHD	Enquire	To Order
	EG33C03014AB	FR ASY W/SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G33F02526AB	Reinforced front body pillar, RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G33F02527AB	Reinforced front body pillar, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8G43C513A07AB	REINFORCED ROOF SIDE RAIL RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8G43C513A08AA	Reinf roof side rail, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	9G4390907AA	Barrel Nut, M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8G43C42220AB	Frame, back window, upper	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	AG3310414AA	MEMBER FRONT CS AT DH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	9G33F01760AA	Panel, dash upper, RH, LHD	Enquire	To Order
	9G33F01760BA	Panel, dash upper, RH, RHD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	9G33F01761AA	Panel, dash upper, LH, LHD	Enquire	To Order
	9G33F01761BA	Panel, dash upper, LH, RHD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	BG33F01612AA	Panel, Dash Side, RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	BG33F01613AA	Panel, Dash Side, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8G4316430AA	REINF HOOD STRIKER PLATE RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8G4316431AA	REINF HOOD STRIKER PLATE LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3356316AA	RIVNUT M8 FLAT HEADED KNURLED 2-3.5 mm GRIP Zn/Ni	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3346768AA	RIVNUT M6/M10L FLAT HEAD 1.5-3mm GRIP Zn/Ni	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8G43199901AA	Nutplate, M6 Headlamp Bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3337949AA	DIA 4.8 X 13.9 BLIND RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4G432010882	SUPPORT ARM ASSY- FRT WING LH-DB9	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4G432010881	SUPPORT ARM ASSY- FRT WING RH-DB9	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3317F790AC	Nutplate, M10	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G33C18178AB	Bracket, Gas Damper Mounting	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	GO8G4316A681AC	REINF HOOD HNGE BODY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	GO8G4316A682AB	RH REINF HOOD HINGE ON BODY LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	700607	Screw Hex Flange Head M6 x 16mm	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	GOAG33F02660AB	Pillar, Front Body Lower Front, RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	GOAG33F02661AB	Pillar, Front Body Lower Front, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3371490AA	Nutplate, A Post Hinge, Upper, RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3315110AB	Nutplate M8, ??post hinge, lower, RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3394545AA	Nutplate, A Post Hinge, Upper, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G3315111AA	Nutplate, A Post Hinge, Upper, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	GOAG33F02662AB	Extrusion, Front Body Pillar Lower, RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	GOAG33F02663AB	Extrusion, Front Body Pillar Lower, LH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6G33486226AA	Nutplate, M8, IP beam	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4G43C03014BR	Frame Assembly, Windshield, RHD	4G43C03014BR Frame Assembly, Windshield, RHD Structural Cat. A only	-	1	Enquire
1	EG33C03014AB	FR ASY W/SHIELD	EG33C03014AB FR ASY W/SHIELD Structural Cat. A only	-	1	Enquire
2	6G33F02526AB	Reinforced front body pillar, RH	6G33F02526AB Reinforced front body pillar, RH Structural Cat. A only	-	1	Enquire
3	6G33F02527AB	Reinforced front body pillar, LH	6G33F02527AB Reinforced front body pillar, LH Structural Cat. A only	-	1	Enquire
4	8G43C513A07AB	REINFORCED ROOF SIDE RAIL RH	8G43C513A07AB REINFORCED ROOF SIDE RAIL RH Structural Cat. A only	-	1	Enquire
5	8G43C513A08AA	Reinf roof side rail, LH	8G43C513A08AA Reinf roof side rail, LH Structural Cat. A only	-	1	Enquire
6	9G4390907AA	Barrel Nut, M6	9G4390907AA Barrel Nut, M6 1 per rail, Structural Cat. A only	-	2	Enquire
7	8G43C42220AB	Frame, back window, upper	8G43C42220AB Frame, back window, upper Structural Cat. A only	-	1	Enquire
8	AG3310414AA	MEMBER FRONT CS AT DH	AG3310414AA MEMBER FRONT CS AT DH Structural Cat. A only	-	1	Enquire
9	9G33F01760AA	Panel, dash upper, RH, LHD	9G33F01760AA Panel, dash upper, RH, LHD Structural Cat. A only	-	1	Enquire
9	9G33F01760BA	Panel, dash upper, RH, RHD	9G33F01760BA Panel, dash upper, RH, RHD Structural Cat. A only	-	1	Enquire
10	9G33F01761AA	Panel, dash upper, LH, LHD	9G33F01761AA Panel, dash upper, LH, LHD Structural Cat. A only	-	1	Enquire
10	9G33F01761BA	Panel, dash upper, LH, RHD	9G33F01761BA Panel, dash upper, LH, RHD Structural Cat. A only	-	1	Enquire
11	BG33F01612AA	Panel, Dash Side, RH	BG33F01612AA Panel, Dash Side, RH Structural Cat. A only	-	1	Enquire
12	BG33F01613AA	Panel, Dash Side, LH	BG33F01613AA Panel, Dash Side, LH Structural Cat. A only	-	1	Enquire
13	8G4316430AA	REINF HOOD STRIKER PLATE RH	8G4316430AA REINF HOOD STRIKER PLATE RH	-	1	Enquire
14	8G4316431AA	REINF HOOD STRIKER PLATE LH	8G4316431AA REINF HOOD STRIKER PLATE LH	-	1	Enquire
15	6G3356316AA	RIVNUT M8 FLAT HEADED KNURLED 2-3.5 mm GRIP Zn/Ni	6G3356316AA RIVNUT M8 FLAT HEADED KNURLED 2-3.5 mm GRIP Zn/Ni 4 per striker plate, Structural Cat. A only	-	8	Enquire
16	6G3346768AA	RIVNUT M6/M10L FLAT HEAD 1.5-3mm GRIP Zn/Ni	6G3346768AA RIVNUT M6/M10L FLAT HEAD 1.5-3mm GRIP Zn/Ni 1 per striker plate	-	2	Enquire
17	8G43199901AA	Nutplate, M6 Headlamp Bracket	8G43199901AA Nutplate, M6 Headlamp Bracket Structural Cat. A only	-	2	Enquire
18	6G3337949AA	DIA 4.8 X 13.9 BLIND RIVET	6G3337949AA DIA 4.8 X 13.9 BLIND RIVET 2 per nut plate, Structural Cat. A only	-	4	Enquire
19	4G432010882	SUPPORT ARM ASSY- FRT WING LH-DB9	4G432010882 SUPPORT ARM ASSY- FRT WING LH-DB9 Structural Cat. A only	-	1	Enquire
20	4G432010881	SUPPORT ARM ASSY- FRT WING RH-DB9	4G432010881 SUPPORT ARM ASSY- FRT WING RH-DB9 Structural Cat. A only	-	1	Enquire
21	6G3317F790AC	Nutplate, M10	6G3317F790AC Nutplate, M10 Structural Cat. A only	-	2	Enquire
22	6G33C18178AB	Bracket, Gas Damper Mounting	6G33C18178AB Bracket, Gas Damper Mounting Structural Cat. A only	-	2	Enquire
23	GO8G4316A681AC	REINF HOOD HNGE BODY	GO8G4316A681AC REINF HOOD HNGE BODY Structural Cat. A only	-	1	Enquire
24	GO8G4316A682AB	RH REINF HOOD HINGE ON BODY LH	GO8G4316A682AB RH REINF HOOD HINGE ON BODY LH Structural Cat. A only	-	1	Enquire
25	700607	Screw Hex Flange Head M6 x 16mm	700607 Screw Hex Flange Head M6 x 16mm 3 reinf hood hinge, Structural Cat. A only	-	6	Enquire
26	GOAG33F02660AB	Pillar, Front Body Lower Front, RH	GOAG33F02660AB Pillar, Front Body Lower Front, RH Structural Cat. A only	-	1	Enquire
27	GOAG33F02661AB	Pillar, Front Body Lower Front, LH	GOAG33F02661AB Pillar, Front Body Lower Front, LH Structural Cat. A only	-	1	Enquire
28	6G3371490AA	Nutplate, A Post Hinge, Upper, RH	6G3371490AA Nutplate, A Post Hinge, Upper, RH Structural Cat. A only	-	1	Enquire
29	6G3315110AB	Nutplate M8, ??post hinge, lower, RH	6G3315110AB Nutplate M8, ??post hinge, lower, RH Structural Cat. A only	-	1	Enquire
30	6G3394545AA	Nutplate, A Post Hinge, Upper, LH	6G3394545AA Nutplate, A Post Hinge, Upper, LH Structural Cat. A only	-	1	Enquire
31	6G3315111AA	Nutplate, A Post Hinge, Upper, LH	6G3315111AA Nutplate, A Post Hinge, Upper, LH Structural Cat. A only	-	1	Enquire
32	GOAG33F02662AB	Extrusion, Front Body Pillar Lower, RH	GOAG33F02662AB Extrusion, Front Body Pillar Lower, RH Structural Cat. A only	-	1	Enquire
33	GOAG33F02663AB	Extrusion, Front Body Pillar Lower, LH	GOAG33F02663AB Extrusion, Front Body Pillar Lower, LH Structural Cat. A only	-	1	Enquire
34	6G33486226AA	Nutplate, M8, IP beam	6G33486226AA Nutplate, M8, IP beam Structural Cat. A only	-	2	Enquire
